BRAKE DRUM NUMERICAL SECTION
Drum
Number
Weight Type Mount
Backface
Thickness
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Special
Information
No. Size
62199F
88
A I
0.44
16.50
8.31 7.62
13.50
15.00 10 0.53
62200F
104
H I
0.50
16.50
9.50 7.38
9.44
11.25 10 0.81 *See footer.
62240F
98
G I
0.50
16.50
8.78 7.41
11.25
12.75 5/6 0.78
62358F
54
A I
0.44
12.25
7.44 6.31
8.50
10.00
6 0.66
62600F
OBSOLETE - Use 61600B**
62670B 113
H O 0.62
16.50
9.69 7.31
8.78
11.25 10 1.09
62671B 113
H O 0.62
16.50
9.69 7.31
8.78
11.25 10 1.31
62671F
113
H O 0.62
16.50
9.69 7.31
8.78
11.25 10 1.31
62997B
96
G I
0.56
16.50
8.69 7.63
10.50
12.75 5/6 0.78
62997F
97
G I
0.56
16.50
8.69 7.63
10.50
12.75 5/6 0.78 *See footer.
62998F
OBSOLETE - Use 62997F
63030B
OBSOLETE - Use 63035B
63031B 114
G I
0.56
16.50
8.40 7.40
10.50
12.75
5 0.78
63032F
105 G I
0.56
16.50
8.23 7.23
11.25
12.75 5/6 0.78
63035F
96
H I
0.56
15.00
8.50 7.50
10.50
12.75 5/6 0.78
63294F
62
G I
0.50
15.00
5.88 4.94
10.00
12.75 5/6 0.78
63410F
133 G I
0.50
16.50 11.06 10.12
9.44
11.00
5 0.78
6 0.66
63427F
84
G I
0.56
16.50
6.50 5.56
9.00
11.25
5 0.78
63436F
80
G I
0.56
16.50
6.25 5.31
9.18
11.25 5/6 0.66
63447F
79
G I
0.56
16.50
6.25 5.31
9.44
11.00
5 0.78
6 0.66
63617F
73
A I
0.44
12.25
9.07 8.00
8.50
10.00
6 0.66
63630F
71
H I
0.50
12.25
8.59 6.25
7.12
8.75
10 0.81
63631F
78
H I
0.50
12.25 10.47 8.12
7.12
8.75
10 0.81
63634F
71
H I
0.50
12.25
8.59 6.25
7.12
8.75
6 0.81
63635F
78
H I
0.50
12.25 10.47 8.12
7.12
8.75
6 0.81
63637F
79
G I
0.44
12.25
9.06 7.81
7.00
8.25
6 0.53
6 0.66
63647F
79
A I
0.44
12.25
9.07 8.00
8.50
10.00
6 0.66
63650F
79
A I
0.56
12.25
9.12 8.40
7.25
8.75
6 0.81
63654F
74
A I
0.56
12.25
8.63 7.91
7.12
8.75
6 0.81
63658F
74
A I
0.56
12.25
8.63 7.91
7.12
8.75
10 0.81
63680F
93
A O 0.50
12.25 11.22 9.95
9.00
10.83
8 1.00 *See footer.
63688F
74
H I
0.50
12.25 10.16 7.81
7.12
8.75
10 0.81
63822F
OBSOLETE - Use 63647F
64002F
OBSOLETE - Use 64004B
64003F
OBSOLETE - Use 64113B
64004B
88
Q O 0.50
14.50
8.00 5.19
12.75
11.25 10 1.31 9.44 Hub Bore
Vert. Ribbed
*See footer.
64004F
OBSOLETE - Use 64004B
64007F
OBSOLETE - Use 64015B
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
