BRAKE DRUM NUMERICAL SECTION
Drum
Number
Weight Type Mount
Backface
Thickness
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Special
Information
No. Size
64404F
78
N I
0.44
15.00
8.00 5.56
6.44
8.75
10 0.78
64405F
78
N I
0.44
15.00
8.00 5.56
6.44
8.75
6 0.81
64408F**
77
H I
0.50
15.00
7.25 5.53
6.25
8.75
6 0.81
64413F
52
A I
0.38
15.00
4.42 3.88
9.00
10.50
5 0.66
64414F
64
G I
0.50
15.00
5.55 4.44
9.19
11.25 5/6 0.66
64417F
66
G I
0.53
15.00
5.38 4.50
9.25
11.25
5 0.78
64425F
31
H I
0.36
14.00
4.00 2.94
4.61
5.5&6 6/6 0.53
64426F
58
H I
0.38
15.00
6.41 4.44
6.25
8.75
6 0.81
64430F
43
K I
0.38
14.00
7.00 3.00
7.12
8.75
6 0.81
64432F
75
K I
0.44
15.00
8.00 5.56
6.51
8.75
10 0.78
64444F
60
G I
0.50
15.00
5.55 4.44
9.19
11.25 5/6 0.78
64445F
65
K O 0.38
15.00
8.25 3.75
9.50
11.25 10 0.81
64449F
65
K O 0.44
15.00
8.06 3.75
7.12
8.75
6 0.81
64453F
44
N I
0.44
15.00
4.69 3.50
6.44
8.00
5 0.66
64454F
73
H O 0.44
15.00
8.53 4.50
8.75
11.25 10 0.81
64464F
OBSOLETE - Use 64414F
64466F
85
H I
0.44
16.50
8.00 6.38
9.38
11.25 10 0.81
64467F
85
H I
0.44
16.50
8.00 6.38
9.44
11.25 10 0.81
64468F
84
H I
0.44
16.50
7.87 6.25
9.44
11.25 10 0.81
64477F
59
G I
0.50
15.00
5.28 4.32
6.44
8.00
5 0.66
64478F
59
N I
0.50
15.00
5.28 4.25
9.50
11.25
6 0.78
64481F
72
H O 0.50
15.00
7.84 4.44
8.66
11.25 10 1.31
64483F
75
H O 0.50
15.00
7.84 4.44
9.44
11.25 10 0.81
64489F
72
H O 0.50
15.00
7.84 4.44
8.78
11.25 10 1.31
65004B
OBSOLETE - Use 64004B
65004F
OBSOLETE - Use 64004B
65119F
OBSOLETE - Use 65119J
65119J
112
O O 0.50
14.50
8.69 6.44
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
65145B 110
F O 0.62
15.00
9.49 6.18
8.78
11.25 10 1.00
65147B 108
F O 0.62
15.00
9.49 6.18
9.00
11.25 10 1.31
65150B
OBSOLETE - Use 65157B
65151B
92
K O 0.50
16.50
9.37 5.45
8.78
11.25 10 1.31
65152B 122
H O 0.62
16.50
9.75 6.50
8.78
11.25 10 1.31 *See footer.
65153B
82
K O 0.50
15.00
9.31 5.40
8.78
11.25 10 1.00
65154B
82
K O 0.50
15.00
9.31 5.40
8.78
11.25 10 1.31
65157B 111
H O 0.62
15.00
9.81 6.50
9.00
11.25 10 1.31
65158B
92
K O 0.50
16.50
9.37 5.45
8.78
11.25 10 1.00
65161B*
116
H O 0.62
16.50
9.38 6.38
8.78
11.25 10 1.31
65162B 123
H O 0.62
16.50
9.75 6.50
8.78
11.25 10 1.00
65162F
123
H O 0.62
16.50
9.75 6.50
8.78
11.25 10 1.00
65163B 119
H O 0.62
16.50
9.52 6.27
8.78
11.25 10 1.00
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
