BRAKE DRUM NUMERICAL SECTION
Drum
Number
Weight Type Mount
Backface
Thickness
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Special
Information
No. Size
64051H
OBSOLETE - Use 64051J
64051J
171
K O 0.59
16.50 11.56 9.44
11.25
13.19 10 1.09 *See footer.
64053B 160
K O 0.59
16.50 11.28 9.16
11.25
13.19 10 1.09 *See footer.
64053F
OBSOLETE - Use 64053B
64054B
OBSOLETE - Use 64053B
64057F
146
H O 0.50
16.50 11.19 8.88
9.00
11.25 10 1.31
64060B
OBSOLETE - Use 64040B
64065F
118
O O 0.50
15.50
8.34 6.37
11.07
13.19 10 1.09
64073B 136
H O 0.50
14.50 11.79 8.50
12.75
11.25 10 1.31 9.44 Hub Bore
64073F
136
H O 0.50
14.50 11.79 8.50
12.75
11.25 10 1.31 9.44 Hub Bore
64089B 133 M O 0.62
16.14 11.81 9.12
14.41
13.19 5/10 0.94 11.73 Hub Bore.
*See footer.
64089F
OBSOLETE - Use 64089B
64089Z
133 M O 0.62
16.21 11.81 9.12
14.41
13.19 10 0.94 11.73 Hub Bore.
64105F
83
N I
0.50
15.00
8.50 6.50
9.75
11.25
5 0.66
64112B 102 O O 0.50
14.50
8.31 6.06
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed
*See footer.
64112F
OBSOLETE - Use 64112B
64113B 102 O O 0.50
14.50
8.31 6.06
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed
64113F
OBSOLETE - Use 64113B
64115B 179 O O 0.50
14.50 12.81 10.50 12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64115C 179 O O 0.50
14.50 12.81 10.50 12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64115F
OBSOLETE - Use 64115B
64115J
179 O O 0.50
14.50 12.81 10.50 12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64117B 110
O O 0.50
14.50
8.69 6.44
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64117F
OBSOLETE - Use 64117B
64117J
110
O O 0.50
14.50
8.69 6.44
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64118F
OBSOLETE - Use 64119B
64119B 110
O O 0.50
14.50
8.69 6.44
12.75
11.25 10 1.31 9.44 Hub Bore,
Circum. Ribbed.
*See footer.
64119F
OBSOLETE - Use 64119B
64120F
OBSOLETE - Use 64119B
64125B 166
F O 0.56
16.50 12.35 9.86
8.78
11.25 10 1.00 *See footer.
64125F
166
F O 0.56
16.50 12.35 9.86
8.78
11.25 10 1.00
64403F
77
K I
0.44
15.00
8.00 5.56
6.51
8.75
6 0.81
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
