BRAKE HARDWARE
BRAKE REPAIR KITS
E-6999SHD STOPMATE PLUS HENDRICKSON, MERITOR and SPICER (DANA) 16-1/2” BRAKES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For Meritor “Q” and Q Plus™,
Spicer (Dana) “Fast Change” and
“XLII”, and Hendrickson Intraax®
brakes. Same as E-2769S minus
Bushings. Same as E-6999S
except has Heavy Duty Return
Spring. Contains new Posi-Plus
roller. For use with the following
Brake Shoes: E-3303 (5”), E-3304
(6”), E-2778 (7”), E-6075 (7”),
E-3522 (8-5/8”), E-3417 (10”).
REPLACES:
Dayton/Batco 08108845, 081701
Leland 4515AQM, K128A
Meritor R508003
Meritor R508003BK
Meritor R508003BULK
Meritor KIT8000MBHD
Meritor KIT8000MBHDBK
Sirco QK1A, QK2HD, QK8HD
2 2
E-2767
Retainer Spring
3 1
E-3490S
Return Spring
4 2
E-11741
Roller
5 2
E-747
Spring Retainer
6 2
E-3007A
Roller Retainer
E-2676 MEGA PLUS MACK 16-1/2” OLD STYLE CAST BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-714
Brake Shoe Wear Pad For use with Mack’s own Old Style
cast shoe with wear plates
REPLACES:
Dayton/Batco 081081
Dayton/Batco 08108110
Meritor R507069
2 1
E-752
Return Spring
3 2
NSS*
Anchor Pin
4 4
E-537
Anchor Pin Felt
5 4
E-671
Felt Retainer
6 4
E-5093
Camshaft Lock Ring
7 4
E-530
Brake Shoe Bushing
E-5086 MEGA PLUS MACK WITH MERITOR 16-1/2” “Q” BRAKE WITH 50,000 LB. REAR AXLE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-5087
Anchor Pin
For use with the following Brake
Shoe: E-5092 (7”)
REPLACES
Dayton/Batco 081115
Dayton/Batco 08111500
Dana/Spicer 82A, TA82A
Haldex CQ62767
Leland K293
Meritor KIT8026HD
Sirco MK2
2 2
E-8938
Anchor Pin Bushing
3 2
E-5088
Retainer Spring
4 1
E-3490B
100 lb Return Spring
5 2
E-5089
Roller
6 2
E-3007A
Roller Retainer
7 2
E-747
Spring Retainer
8 2
NSS*
Retainer Pin Spring
9 2
E-5091
Lock Ring
10 1
E-3887
Anti-Seize Compound
*Not Sold Separately
