BRAKE HARDWARE
BRAKE REPAIR KITS
E-2769SHD STOPMATE PLUS HENDRICKSON, MERITOR and SPICER (DANA) 16-1/2” BRAKES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For Meritor “Q” and Q Plus™,
Spicer (Dana) “Fast Change” and
“XLII”, and Hendrickson Intraax®
brakes. Contains new Posi-Plus
roller. Same as E-2769S except
has Heavy Duty Return Spring.
For use with the following Brake
Shoes: E-3303 (5”), E-3304 (6”),
E-2778 (7”),
E-6075 (7”), E-3522 (8-5/8”),
E-3417 (10”). Note: To insure
quick brake release and full lining
life, Q Plus™ brakes use only
heavy-duty return springs.
REPLACES:
Dayton/Batco 08108800,
08108838,08108865, 081132,
081703
Dana/Spicer 291A, 291ABULK,
291AR, 291ARBULK, TA291A
Sirco 45154707QHD
Haldex 66867, CQ66867,
WKH1EZT, E2769SHDR
Leland K128, K128K, K329,
K332, 4515AQHD
Meritor KIT8000HD,
KIT8000HDBK,
R508001, R508001BK,
R508001BULK
2 2
E-1893S
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-3490S
Return Spring
5 2
E-11741
Roller
6 2
E-747
Spring Retainer
7 2
E-3007A
Roller Retainer
E-6999S STOPMATE PLUS HENDRICKSON, MERITOR and SPICER (DANA) 16-1/2” BRAKES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2766S
Anchor Pin
For Meritor “Q” and Q Plus™,
Spicer (Dana) “Fast Change” and
“XLII”, and Hendrickson Intraax®
brakes. Same as E-2769S minus
Bushings.Contains new Posi-Plus
roller. For use with the following
Brake Shoes: E-3303 (5”), E-3304
(6”), E-2778 (7”), E-6075 (7”),
E-3522 (8-5/8”), E-3417 (10”).
REPLACES:
Dayton/Batco 08108810,
08108815,08108815, 081425,
081700
Dana/Spicer 30A, 30AR, HK29
Leland K321, K70A
Meritor KIT8000MB ,
KIT8000MBA
Meritor KIT8000MBBK,
KIT8000MBBULK
Meritor R508002, R508002BK,
R508002BULK
Sirco QK-2,QK8,QK8A
2 2
E-2767
Retainer Spring
3 1
E-2768
Return Spring
4 2
E-11741
Roller
5 2
E-747
Spring Retainer
6 2
E-3007A
Roller Retainer
