BRAKE HARDWARE
CAM BRAKE SHOES
16-1/2” DIAMETER
UNLINED
SHOE NO.
REPLACES
SIZE FMSI NO.
RIVET
USE BRAKE
REPAIR KIT
APPLICATION
E-6075
Meritor A3222N1496
16-1/2”
x 7”
4515E 10-8
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor for Fruehauf “XEM”
Brake. Mfg. Stamping No.:
F5 (Web)
E-2687
Meritor A3722D82
16-1/2”
x 5”
4524B 10-8
KIT-4 Series,
E-1816 Series
Meritor “P” Brake Front
Axle
E-2241
Meritor A3722N66
16-1/2”
x 7”
4515E 10-8
KIT-4 Series,
E-1816 Series
Meritor “P” Brake for
Tractor and Trailer
E-3303
Meritor A3222E1383
16-1/2”
x 5”
4524B 10-8
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor “Q” Brake Mfg.
Stamping No.: 3222-Q-
1291 (Web)
E-3823
Meritor A3222J1440
16-1/2”
x 5”
4524B 10-8
E-9644, E-9644
(Contains E-9643
offset-center bar
spring)
Meritor “Q” Brake Special
for Mack. Relocated Return
Spring. Mfg. Stamping No.:
3222-U-1347 (Web)
E-3304
Meritor A3222C1381
16-1/2”
x 6”
4514G 10-8
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor “Q” Brake
E-9780
Meritor A3222V1348
16-1/2”
x 6”
4514G 10-8
E-9644 E-9644
(Contains E-9643
offset-center bar
spring)
Meritor “Q” Brake Special
for Mack. Relocated Return
Spring. Mfg. Stamping No.:
3222-U-1347 (Web)
E-5092
Meritor A3222S1735
16-1/2”
x 7”
4515H 10-8
E-5086
Meritor “Q” Brake with 3/8”
Thick Web
E-3522
Meritor A3222T1346
16-1/2” x
8-5/8” 4551B 10-8
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor “Q” Brake
E-3417
Meritor A3222D1356
16-1/2” x
10”
4514G,
4549C 10-8
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor “Q” Brake
