BRAKE HARDWARE
CAM BRAKE SHOES
16-1/2” DIAMETER
UNLINED
SHOE NO.
REPLACES
SIZE FMSI NO.
RIVET
USE BRAKE
REPAIR KIT
APPLICATION
E-10854
Meritor A3222Z2288
16-1/2”
x 5”
4720 10-9
E-9644
Meritor Q Plus™ Brake.
NOTE: Euclid recommends
using only Heavy-Duty
Return Springs with Q
Plus™ Brakes.
E-10847
Meritor A3222P2200
16-1/2”
x 6”
4715 10-9
E-9644
Meritor Q Plus™ Brake.
NOTE: Euclid recommends
using only Heavy-Duty
Return Springs with Q
Plus™ Brakes.
E-5503
Meritor A3222D2006
16-1/2”
x 7”
4707 10-9
E-2769 Series
Meritor Q Plus™ Brake.
NOTE: Euclid recommends
using only Heavy-Duty
Return Springs with Q
Plus™ Brakes.
E-10850
Meritor A3222J2272
16-1/2”
x 8”
4718 10-9
E-2769 Series
Meritor Q Plus™ Brake.
NOTE: Euclid recommends
using only Heavy-Duty
Return Springs with Q
Plus™ Brakes.
E-10844
Meritor A3222K2169
16-1/2” x
8-5/8” 4711 10-9
E-2769 Series
Meritor Q Plus™ Brake.
NOTE: Euclid recommends
using only Heavy-Duty
Return Springs with Q
Plus™ Brakes.
E-2778
Meritor A91-3222S1293
Meritor A3222S1293
Spicer M16WS103X
Fruehauf ACF04362-001
E-2769 Series,
E-3895 Series,
E-6999 Series
Meritor Appl
.
E-5515 Spicer
Applications
Meritor “Q” Brake.
Spicer “XL” “Xtralife”
Brake.
16-1/2”
x 7”
4515E
Meritor,
4701
Spicer
10-8
Meritor,
10-9
Spicer
18” DIAMETER
UNLINED
SHOE NO.
REPLACES
SIZE
FMSI NO.
RIVET
USE BRAKE
REPAIR KIT
APPLICATION
E-2801
Eaton 1003017
18” x 7” 4527B
E-2821
Eaton Single Anchor Pin
Mack, Navistar - Cast Iron
E-4902
Meritor A1-3222B1952 18” x 7” 4471B 10-10
E-3992
Meritor - Cast Iron
E-5500
Spicer M16WS100X
Standard Forge 201144
18” x 7” 4284
E-5499
Spicer and Std. Forge
