BRAKE HARDWARE
DUST SHIELDS
FOR MERITOR TRAILER APPLICATIONS WITH FABRICATED STEEL SPIDERS
BRAKE SIZE
EUCLID NO.
REPLACES
A
B
C
D
E
F
16-1/2” x 6”,
16-1/2” x 7”
E-9095AHD
1
E-9095A
18-1/4”
14-3/8”
5-1/4”,
5-3/4”
11”
2-3/4”
5/8”
Dayton/Batco 02515
Leland L3160
Meritor R009095
DUST SHIELD MOUNTING KIT FOR MERITOR FABRICATED STEEL SPIDERS
EUCLID NO.
INCLUDES
REMARKS
E-10243
1 ABS Grommet
2 Dust Plugs
4 Dust Spacers
4 Mounting Screws
For use with E-9095 Dust Shield. Services one
Dust Shield. Torque spec 25-35 ft.lb.
1 IIncludes Spacers
