BRAKE HARDWARE
BRAKE SPIDERS - TRAILERS ONLY
12-1/4” DIAMETER
EUCLID NO.
REPLACES
PILOT
DIA.
BOLT
CIRCLE
DIA.
HOLE
DIA.
NO. OF
MTG.
HOLES
GENERAL INFORMATION
E-1108
Dayton/Batco 02125
Standard Forge 200999002
Trailmobile 21L438
Dana/Spicer 361653
Trailmobile 381108
Haldex 66561
Meritor R001108
5-5/8”
Brake Spider for 12-1/4”
Brakes. For Std. Forge Axles
not drilled for Dust Shields.
INCLUDES:
E-759 Bushing and E-1416
Seal. No longer includes
Anchor Bolt
16-1/2” DIAMETER
E-959
Kit contains:
1 E-957 Brake Spider
1 E864 Brake Flange
16 E-632 Spider Mounting
Bolts &
Nuts
Brake Spider and Flange
Mounting Kit for 16-
1/2” Brakes. For Meritor
Standard TK500 Series and
Eaton 18,000 lb. Axles.
Also Std. Forge 17,000 and
18,000 lb. Axles.
E-957
Dayton/Batco 02132
Dayton/Batco 02136
Standard Forge 200999010
Dana/Spicer 361645
Dana/Spicer 361647
Trailmobile 38957
Haldex 65363
Trailmobile 700723
Trailmobile 7A13
Meritor A3211A833
Eaton B15931
Leland L517
Dana/Spicer M16WS135X
5-5/8” 6-5/8” 1/2”
16
Bolt-On Spider Assembly for
16-1/2” Brakes. Easy
Anchor Pin Removal and
Replacement. Prevents
Bending of Spiders Caused
by Driving Out Frozen
Anchor Pins. Allows
Adjustment for Wear.
INCLUDES: E-1416 Seal and
E-759 Bushing
BRAKE AND AXLE PARTS
BRAKE FLANGE
EUCLID NO.
REPLACES
PILOT DIA.
BOLT
CIRCLE
DIA.
HOLE DIA.
NO. OF
MTG.
HOLES
GENERAL INFORMATION
E-864
Dayton/Batco 02400
Standard Forge
102102002
Dana/Spicer 6261
Eaton B13231
Leland L441
Dana/Spicer M16TF101
Meritor R00864
5-1/8” 6-5/8” 1/2”
16 Brake Flange for 5” Dia.
Axles
BRAKE SPIDER MOUNTING BOLT AND NUT
EUCLID NO.
REPLACES
BOLT DIAMETER
BOLT LENGTH
GENERAL INFORMATION
E-632
Dana/Spicer 361657
Trailmobile 38632
Leland L219
Meritor R00632
1/2”
1-13/16”
Grade 8. Saves valuable
time when replacing Spider
Bolt and Nut. Made from
Alloy Steel and Hardened for
Super Strength.
