CAMSHAFTS
EUCLID CAMSHAFT E.S.P. GUIDE
LENGTH
HEAD
TYPE
SPLINE JRNL. DIA.
EUCLID
NO.
HEAD
END* AXLE
CAMSHAFT KIT
MFR./BRAKE SIZE
NOTES
23-15/16” 5 1-1/2”-28 1-5/8”
E-10907
LH
T E-9790A
Spicer 12-1/4”
0794L/R Head Fast-Rise
E-10908
RH
24”
1 1-1/2”-10 1-1/2”
E-4717
LH
T See Camshaft pages Multi-App 16-1/2”
Single Groove Journal
E-4716
RH
24”
2 1-1/2”-10 1-1/2”
E-9727
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-9728
RH
24-1/16” 11 1-1/2”-10 1-5/8”
E-2451A
LH
T See Camshaft pages Meritor 16-1/2” Q Plus
E-2452A
RH
24-1/16”
2 1-1/2”-28 1-1/2”
E-9100
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-9101
RH
24-1/16” 11 1-1/2”-28 1-5/8”
E-5510
LH
T
E-9078HD (Press-In
Bushing), E-9079HD
(Bolt-On Bushing)
Meritor 16-1/2” Q Plus
E-5511
RH
24-1/16” 11 1-1/2”-28 1-5/8”
E-2445B
LH
T See Camshaft pages
Meritor 16-1/2” P, Q, Q
Plus
E-2446B
RH
24-1/8”
2 1-1/2”-28 1-5/8”
E-10909
LH
T E-11910, E-9790A Spicer 16-1/2” XL
Single Groove Journal 2-7/32”
E-10910
RH
24-3/8”
1 1-1/2”-10 1-1/2”
E-2797
LH
T See Camshaft pages Multi-App 16-1/2”
Single Groove Journal
E-2796
RH
24-3/8”
2 1-1/2”-10 1-1/2”
E-6103
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-6104
RH
24-5/8”
3 1-1/2”-10 1-1/2”
E-2793
LH
T
E-2469 (Nylon
Bushing)
Spicer 12-1/4”
Standard Head
E-2792
RH
24-5/8”
4 1-1/2”-28 1-1/2”
E-10927
LH
T E-2469
Dexter 12-1/4”
Single Groove Journal
E-10928
RH
25-3/4”
1 1-1/2”-10 1-1/2”
E-4719
LH
T See Camshaft pages Multi-App 16-1/2”
Single Groove Journal
E-4718
RH
*Left or Right Hand description refers to the rotation of the Camshaft Head. This description does not always match the position of the Camshaft on the axle.
AXLE = S-Steering; D-Drive; T-Trailer
