CAMSHAFTS
BRAKE CAMSHAFTS — STEERING AXLE
FOR EATON STEERING AXLES WITH 15” SINGLE ANCHOR PIN BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-5058
LH
1-1/4”
Eaton 1006724
7-5/8”
E-5140
E-5139
E-5059
RH
Eaton 1006725
E-5060
LH
1-1/4”
Eaton 1006730
8-9/16”
E-5140
E-5139
E-5061
RH
Eaton 1006731
E-5066
LH
1-1/4”
Eaton 1008006
8-15/16”
E-5140
E-5139
E-5067
RH
Eaton 1008007
E-5131
LH
1-1/4”
Eaton 1006866
9-3/16”
E-5140
E-5139
E-5132
RH
Eaton 1006867
E-5133
LH
1-1/4”
Eaton 1006728
9-9/16”
E-5140
E-5139
E-5134
RH
Eaton 1006729
E-5135
LH
1-1/4”
Eaton 1006940
9-25/32”
E-5140
E-5139
E-5136
RH
Eaton 1006941
E-5062
LH
1-1/4”
Eaton 1006864
10-29/32”
E-5140
E-5139
E-5063
RH
Eaton 1006865
FOR EATON STEERING AXLES WITH 15” “ES” “EXTENDED SERVICE” BRAKES
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9028
LH
1”
Eaton 813486
7-15/16”
E-5140
E-5139
These cams are “extended life”
versions of this manufacturer’s
“standard version”. If retrofitting
from “standard” to “extended
life” camshafts. Euclid strongly
recommends replacing both
cams on a single axle or all
cams on tandem axles to
promote a balanced brake
condition.
E-9029
RH
Eaton 813487
E-9030
LH
1”
Eaton 813480
9-3/16”
E-5140
E-5139
E-9031
RH
Eaton 813481
E-9032
LH
1”
Eaton 813482
9-9/16”
E-5140
E-5139
E-9033
RH
Eaton 813483
E-9034
LH
1”
Eaton 813494
9-25/32”
E-5140
E-5139
E-9035
RH
Eaton 813495
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
