CAMSHAFTS
CAMSHAFT REPAIR KITS
E-2696A-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-2695
1 1 Camshaft Bushing
FOR LATE MODEL EATON TRAILER
AXLE
With “501” Series Brakes and
“ES” Brakes with Long Life
Cam Support Bushings. Half
kit includes exactly half of Kit
E-2696A for one wheel end.
E-1565
2 2 Camshaft Spacer Washer
E-580
3 2 Camshaft Spacer Washer
E-2405
4 2 Camshaft Seal
E-2690A
5 1 Camshaft Bushing
E-1569
6 1 Camshaft Lock Ring
E-526
7 1 Camshaft Lock Ring
E-801
8 1 Lock Ring
E-5137
9 1 Camshaft Spacer Washer
E-3520A For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-564
1 2 Camshaft Spacer Washer
FOR LATE MODEL MERITOR 4000-
6000 SERIES TRAILER AXLES
With 1-5/8” Dia. Camshafts.
Also used for 12-1/4” “Q”
Brakes. Contains Lock Rings for
Camshafts with narrow or wide
grooves.
E-1318A
2 2 Camshaft Support Bracket
E-801
3 2 Lock Ring
E-2405
4 2 Camshaft Seal
E-2406
5 2 Camshaft Seal
E-2407
6 2 Camshaft Outer Bushing
E-2408
7 2 Camshaft Inner Bushing
E-1569
8 2 Camshaft Lock Ring
E-1113
9 2 Washer
E-2411A
10 4 Camshaft Spacer Washer
E-5093
11 2 Camshaft Lock Ring
E-3520A-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-564
1 1 Camshaft Spacer Washer
FOR LATE MODEL MERITOR 4000-
6000 SERIES TRAILER AXLES
With 1-5/8” Dia. Camshafts.
Also used for 12-1/4” “Q”
Brakes. Contains Lock Rings for
Camshafts with narrow or wide
grooves. Half kit includes exactly
half of Kit E-3520A for one wheel
end.
E-1318A
2 1 Camshaft Support Bracket
E-801
3 1 Lock Ring
E-2405
4 1 Camshaft Seal
E-2406
5 1 Camshaft Seal
E-2407
6 1 Camshaft Outer Bushing
E-2408
7 1 Camshaft Inner Bushing
E-1569
8 1 Camshaft Lock Ring
E-1113
9 1 Washer
E-2411A
10 2 Camshaft Spacer Washer
E-5093
11 1 Camshaft Lock Ring
