CAMSHAFTS
CAMSHAFT REPAIR KITS
E-9078HD02 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-6080
1 1 Camshaft Bushing
FOR MERITOR “Q” AND Q PLUS
TRAILER AXLE BRAKES WITH
PRESS-IN POWDERED METAL
SPIDER BUSHING
Contains enough parts to
service Forged or Fabricated
Brake Spiders and Camshafts
with either 1-25/32” or 2-5/64”
Camshaft Journal. Contains
E-1318AHD Heavy-Duty Support
Assembly. Half kit includes
exactly half of KIT E-9078HD for
one wheel end.
E-1318AHD
2 1 Camshaft Support Bracket
E-2405
3 2 Camshaft Seal
E-2411A
4 2 Camshaft Spacer Washer
E-9073
5 1 Camshaft Head Washer
E-1113
6 2 Washer
E-564
7 1 Camshaft Spacer Washer
E-9074
8 1 Camshaft Spacer Washer
E-9075
9 1 Camshaft Spacer Washer
E-5093
10 1 Camshaft Lock Ring
E-1569
11 1 Camshaft Lock Ring
E-9077
12 1 Camshaft Lock Ring
E-801
13 1 Lock Ring
E-9079 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-6076
1 2 Camshaft Bushing
FOR MERITOR “Q” AND Q PLUS
TRAILER AXLE BRAKES WITH BOLT-
ON POWDERED METAL SPIDER
BUSHING ON FABRICATED SPIDERS
E-1318A
2 2 Camshaft Support Bracket
E-5093
3 2 Camshaft Lock Ring
E-1113
4 2 Washer
E-564
5 2 Camshaft Spacer Washer
E-6077
6 2 Camshaft Washer
E-2405
7 4 Camshaft Seal
E-9072
8 2 Camshaft Spacer Washer
E-9077
9 2 Camshaft Lock Ring
NSS*
10 8 Screw
E-801
11 2 Lock Ring
E-9079HD For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-6076
1 2 Camshaft Bushing
FOR MERITOR “Q” AND Q PLUS
TRAILER AXLE BRAKES WITH
BOLT-ON POWDERED METAL
SPIDER BUSHING ON FABRICATED
SPIDERS
Contains E-1318AHD Heavy-Duty
Support Assembly.
E-1318AHD
2 2 Camshaft Support Bracket
E-5093
3 2 Camshaft Lock Ring
E-1113
4 2 Washer
E-564
5 2 Camshaft Spacer Washer
E-6077
6 2 Camshaft Washer
E-2405
7 4 Camshaft Seal
E-9072
8 2 Camshaft Spacer Washer
E-9077
9 2 Camshaft Lock Ring
NSS*
10 8 Screw
E-801
11 2 Lock Ring
