CAMSHAFTS
CAMSHAFT REPAIR KITS
E-9079HD-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-6076
1 1 Camshaft Bushing
FOR MERITOR “Q” AND Q PLUS
TRAILER AXLE BRAKES WITH
BOLT-ON POWDERED METAL
SPIDER BUSHING ON FABRICATED
SPIDERS
Contains E-1318AHD Heavy-
Duty Support Assembly. Half
kit includes exactly half of Kit
E-9079HD for one wheel end.
E-1318AHD
2 1 Camshaft Support Bracket
E-5093
3 1 Camshaft Lock Ring
E-1113
4 1 Washer
E-564
5 1 Camshaft Spacer Washer
E-6077
6 1 Camshaft Washer
E-2405
7 2 Camshaft Seal
E-9072
8 1 Camshaft Spacer Washer
E-9077
9 1 Camshaft Lock Ring
NSS*
10 4 Screw
E-801
11 1 Lock Ring
E-9080 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-5512
1 4 Camshaft Bushing
FOR MERITOR “P” and “Q”
DRIVE AXLE BRAKES WITH 2-1/2”
SPIDER OFFSET
Contains New Style E-5512
Moly-impregnated Spider
Bushing. Contains Lock Rings for
Camshafts with narrow or wide
grooves. Commonly found on
Mack Trucks.
E-654
2 4 Camshaft Seal
E-9071
3 2 Camshaft Head Washer
E-580
4 2 Camshaft Spacer Washer
E-581
5 2 Camshaft Spacer Washer
E-526
6 4 Camshaft Lock Ring
E-4736
7 2 Camshaft Lock Ring
E-3859
8 2 Camshaft Seal
E-9790A-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-9789
1 1 Camshaft Bushing
FOR SPICER (DANA) 16-1/2”
BRAKE WITH 1-5/8” CAM
JOURNAL
Half kit includes exactly half of
Kit E-9790A for one wheel end.
E-9792A
2 1 Camshaft Bushing
E-2405
3 2 Camshaft Seal
E-1569
4 1 Camshaft Lock Ring
E-801
5 1 Lock Ring
E-10800
6 1 Cam Washer
E-580
7 1 Camshaft Spacer Washer
E-1113
8 2 Washer
E-10801
9 1 Cam Washer
