47 / 105
46
Copyright © 2015 KIC LLC
Assembly PN
Description
Drum PN
6.00
8.08
11.03
335mm (13.19")
6 Holes 1/4"-20 UNC,
7.25 Bolt Circle
N/A
N/A
SAE "A65" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 10 stud hub w/ 335mm Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
9442 Series Assemblies
892 / 896
6535 / 6580
Std. Hub Weight
91 lbs.
014-09442
Hub Pilot M24 x 5.47 Stud, 18 x 7" Drum
54304-01
18.00 7.67
11.25 11.95
M24 x 1.5
2.74
10.15
291
1.80
PRT-04565
Notes
Uses PRT-00110 1.5 x M24 Flange Nut
