Assembly PN
Description
Drum PN
2.91
4.22
6.09
275mm (10.827")
6 Holes 5/16"-18 UNC,
4.50 Bolt Circle
N/A
5.24
SAE "N/A" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 8-stud hub w/ 275mm Dia. Bolt Circle. Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
5110 Series Assemblies
39520 / 39581
3820 / 3877
Std. Hub Weight
37 lbs.
012-05110L
Hub Pilot M22 x 1.5 Stud, 12.8" x 4" Drum Bal
54289-018
12.80 6.14
9.00
6.54
M22 x 1.5
2.55
2.74
83
3.79
PRT-00121
