Assembly PN
Description
Drum PN
2.91
4.17
5.94
205.05 mm (8.07")
4 Holes 5/16"-18 UNC,
3.63 Bolt Circle
0.98
4.32
SAE "I80 (FC)" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 6 stud hub w/ 8.07" Dia Bolt Circle. Uses Outboard Drum - Clipped Head Stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
4000 Series Assemblies
JM207010 / JM207049A
25820 / 25877
Std. Hub Weight
25 lbs.
011-04000L
Hub Pilot M18 x 3.15 Stud, 12.80 x 4" Drum Bal
54256-018
12.80 4.25
6.52
6.52
M18 x 1.5
2.13
2.82
71
3.72
PRT-01296
Option "T" - ABS Tone Ring
6.25
PRT-00982
100-Tooth Tone Ring
Part Number
Description
Pitch Diameter
Notes
KIC recommends 300-400 ft. lbs. torque range on the M18 studs for the
011-04000
Uses PRT-00116 Flange Nut
