Assembly PN
Description
Drum PN
2.91
4.22
6.08
205.05mm (8.07")
6 Holes 5/16"-18 UNC,
4.06 Bolt Circle
N/A
5.24
SAE "N/A" Spindle
Inner Bearing Cup / Cone
Outer Bearing Cup / Cone
Ductile Iron 6 stud hub w/ 205.05mm Dia. Bolt Circle, Uses Outboard Drum - Serrated stud
Hub Specifications
A: Hub Overall Length
B: Inner Cup to Mounting Face
C: Distance Between Cups
D: Tone Ring Bore Diameter
E: Tone Ring Bore Depth
J: Bolt Circle
K: Bolt Pattern
L
Brake
Face Dia
P
Brake
Face Width
I
Hub Pilot
N
Overall
Depth
G - Stud PN M - Cup
to Drum
Thread Stud Stand
Out
O
Cup Face
to Mtg.
Assy
Weight
Drum
5010 Series Assemblies
39520 / 39581
3820 / 3877
Std. Hub Weight
27 lbs.
012-05010L
Hub Pilot M18 x 1.5 Stud, 12.8" 4.35" Drum Bal
54256-018
12.80 4.25
6.52
6.52
M18 x 1.5
2.13
2.74
73
4.22
PRT-01296
Notes
KIC recommends 300-400 ft. lbs. torque range on the M18 studs for the
011-04000
Uses PRT-00116 Flange Nut
