Component Parts
Rim Nuts
Inner Cap Nuts
Part No.
Inner
Thread
Outer
Thread
A
Square
B
Length
C
Inner
Thread
Depth
Notes
PRT-05549L
3/4 - 16 1-1/8 - 16 0.81
2.24
1.25 Standard for
Dual Steel
Wheels
PRT-05549R
3/4 - 16 1-1/8 - 16 0.81
2.24
1.25
Lock Nuts
Flange Nuts
Part No.
Thread Size
A
Hex Size
B
Height
PRT-00075
3/4 - 10
1.12
0.72
Part No.
Thread Size
A
Hex Size
B
Height
PRT-00144
5/8 - 18
1.12
0.65
PRT-00152
3/4 - 16
1.12
0.65
Part No.
Thread Size
A
Hex Size
B
Height
PRT-00110
M24 x 1.5
1.42
1.34
PRT-00115
M22 x 1.5
1.30
1.22
PRT-00116
M18 x 1.5
1.06
0.97
