Shoulder Studs
Clipped Head Studs
Component Parts
Rim Studs
Part No.
A
B
C
D
E
Thread
PRT-01296 3.15
0.71
0.63
2.05 M18 x 1.5
Part No.
A
B
C
D
E
F
G
H
4.00
0.78
2.47
1.06
1.34
1.08 3/4-16 RH 3/4-16 RH
PRT-00875 4.00
0.78
2.47
1.06
1.34
1.08 3/4-16 LH 3/4-16 RH
Part No.
A
Wheel End Nut End
Thread
B
C
PRT-00114
3.00
0.97
1.83
3/4-10
