Rim Spacer Bands
Serrated Studs
Component Parts
Part No.
Size
PRT-04015
15 x 4”
PRT-04020
20 x 4”
Part No.
A
B
C
D
E
Thread
PRT-00117
3.94
0.98
0.72
0.25
2.88
M22 x 1.5
PRT-00118
4.79
0.98
0.72
0.25
3.73
M22 x 1.5
PRT-00121
3.70
0.98
0.72
0.25
2.58
M22 x 1.5
PRT-00122
4.25
0.98
0.72
0.25
3.19
M22 x 1.5
PRT-00983
3.04
0.98
0.70
0.26
2.06
M22 x 1.5
PRT-01292
2.72
0.98
0.81
0.22
1.50
3/4-16 RH
PRT-01293
2.72
0.98
0.81
0.22
1.50
3/4-16 LH
PRT-01294
3.13
0.98
0.81
0.25
1.63
3/4-16 RH
PRT-01295
3.13
0.98
0.81
0.25
1.63
3/4-16 LH
PRT-04565
5.47
0.98
1.25
0.24
3.76
M24 x 1.5
