C.V. HEAD ASSEMBLIES
Overall
Length
CL to Point
of Weld
CL to CL of
Center Yoke Butt Dia. Bolt Circle Dia.
Bolt Hole
Spacing
Across Yoke
Bolt Hole
Spacing
Across Ears Bolt Hole Size Style
C.V. Head
Assembly
3R SERIES U-JOINT KIT: CP3147X
6.563"
1.625"
3.250"
1.766"
4.25"
.453"
2
4137268
131N SERIES U-JOINT KIT: CP153X
4.094"
1.438"
2.688"
1.766"
2.344"
1.50"
.313” - 24
1
R912777
4.125"
1.438"
2.688"
2.344"
2.344"
1.50"
.313” - 24
1
R912747
C.V. HEAD ASSEMBLIES COMPONENT PART NUMBERS
Ball Stud Yoke
Center Yoke "H"
Type
Centering Yoke
Flange Socket
Tubing
Style C.V. Head Assembly
3R SERIES U-JOINT KIT: CP3147X (2 Reqd.)
R3R-28-869
R3R-26-57
R3R-83-482
2.00" x .120" (11 GA)
2
4137268
131N SERIES U-JOINT KIT: CP153X (2 Reqd.)
131N-28-2957X
131N-26-497
131N-CV82-HD
2.00" x .120" (11 GA)
1
R912747
131N-28-2947X
131N-26-497
131N-CV82-HD
2.00" x .120" (11 GA)
1
R912777
C.V. CENTERING YOKES
Distance Between
Nibbs
Bearing Cap
Diameter
Swing Diameter Bolt Hole Size
Bolt Hole
Spacing
Across Yoke
Bolt Hole
Spacing Ears
Stud Socket
Dimension
Part Number
131N SERIES U-JOINT KIT: CP153X
3.47"
1.06"
3.50"
.313” - 24
UNF
2.34"
1.50"
.50"
131N-CV82-HD
