FLANGE YOKES — DOUBLE CARDAN C.V. HEAD — STYLE 1 AND 2
Center
to Face
Pilot Dia.
M=Male
F=Female
Bolt
Circle
Dia.
Yoke
Dim.
Across
Ears
Brg.
Cap
Dia.
Bolt
Hole
Dia.
No. of
Bolt
Holes
Inside
Snap
Ring
Dim.
Flange
O.D.
Stud
Socket
Dim.
Style
Part Number
3R SERIES U-JOINT KIT: CP3147X
1.69"
F-3.13"
4.25"
3.56"
1.13"
.453"
4
2.56"
5.13"
.906"
2
R3R-83-482
121N SERIES U-JOINT KIT: CP443X
1.63"
F-2.00"
3.50"
2.69"
1.06"
.500"
4
4.38"
.500"
1
121N-83-489X
FLANGE YOKES — DOUBLE CARDAN C.V. HEAD — STYLE 3
Center
to Face
Pilot Dia.
M=Male
F=Female
Bolt
Circle
Dia.
Yoke
Dim.
Across
Ears
Brg.
Cap
Dia.
Bolt Hole
Dia.
No. of
Bolt
Holes
Inside
Snap
Ring
Dim.
Flange
O.D.
Stud
Socket
Dim.
Style
Part Number
131N SERIES U-JOINT KIT: CP153X
2.91" M-1.81", 46mm
1.06" .315", 8mm 4
4.44"
3
131N-83-288X
1.63" F-2.00"
3.50"
3.47"
1.06" .500"
4
4.38"
.500"
1
131N-83-388X
