BALL STUD WELD YOKES — INSIDE SNAP RING
Use with Tubing
O.D. and Wall
Butt Dia.
CL to
Weld
Point
CL to End
of Ball
Stud
Ball Stud
Dia.
Yoke Dim.
Across
Ears
Brg. Cap
Dia.
ISR Dim.
Maximum
Operating
Angle
Weld Yoke
Part Number
3R SERIES U-JOINT KIT: CP3147X
2.00" x .120" (11 GA) 1.77"
1.63"
2.00"
.91"
3.56"
1.13"
2.56"
17°
R3R-28-869
BALL STUD WELD YOKES — OUTSIDE SNAP RING
Ball Stud
Use with Tubing O.D.
and Wall
Butt Dia.
Center
Line to
Weld
Point
Center
Line to
End of
Ball Stud Length Dia.
Yoke Dim.
Across Ears
Brg. Cap
Dia.
Maximum
Operating
Angle
Weld Yoke Part
Number
131N SERIES U-JOINT KIT: CP153X
2.50" x .083" (14 GA)
2.34"
1.44"
1.64"
.59"
.50"
3.47"
1.06"
13°
131N-28-1747X
1280 and 131N SERIES U-JOINT KIT: CP153X
2.00" x .120" (11 GA)
1.77"
1.44"
1.64"
.59"
.50"
3.47"
1.06"
13°
131N-28-1777X
2" x .120" (11 GA)
1.77"
1.44"
1.64"
.59"
.50"
3.47"
1.06"
13°
131N-28-2947X
131N SERIES U-JOINT KIT: CP153X
2.50" x .083" (14 GA)
2.34"
1.44"
1.64"
.59"
.50"
3.47"
1.06"
13°
131N-28-2957X
133N SERIES U-JOINT KIT: CP153X
2.50" x .083" (14 GA)
2.34"
1.38"
1.67"
.59"
.50"
3.875"
1.06"
133N-28-3067X
135N SERIES U-JOINT KIT: CP153X
3.00" x .083" (14 GA)
2.84"
1.44"
1.73"
.59"
.50"
3.875"
1.19"
135N-28-1327X
1 Used primarily in crank driven front mount hydraulic pump applications. Also suitable for clutch connection drives. Maximum operating speed 2800 rpm. (Not recommended for vehicular propeller shaft applications.)
