SPLINE PLUG SHAFT FOR AUXILIARY POWER TAKE—OFF
Spline Size
Overall Length
Length of Spline
Dust Cap
Insert Diameter
End Yoke
Part Number
WELDED APPLICATION
1.38” - 16
24"
2.50"
R280194
1.25"
131N-4-533
131N-40-138-2
131N SERIES AUXILIARY POWER TAKE—OFF KITF
Series
Slip Yoke
Spline Plug Shaft
U-Joint Kit
End Yoke
Driveshaft Kit Part
Number
DRIVESHAFT COMPONENT PART NUMBERS
131N
131N-3-7981KX
131N-40-138-2
CP153X
131N-4-533
R91382SF
1
131N SERIES AUXILIARY POWER TAKE—OFF
UNWELDED DRIVESHAFT ASSEMBLY
Series
Maximum
Assembly
Length
Minimum
Assembly
Length
Tubing
Yoke and
Tube Length
Maximum
Length
Minimum
Length
Complete Driveshaft
Part Number
DRIVESHAFT SPECIFICATIONS
1280, 131N
55.75"
9.50"
2.00" x .083" (14 GA)
49.44"
8.25"
6.25"
R9553-SF
1000, 10N
69.39"
10.00"
2.00" x .083" (14 GA)
59.91"
9.48"
7.48"
R10270-SF
DRIVESHAFT COMPONENT PART NUMBERS
Series
Slip Yoke
Spline Plug
Weld Yoke
U-Joint Kit
Tubing
Complete Driveshaft
Part Number
1000, 10N
10N-3-18KX
121N-40-1741
R10V5
CP170X
2.00" x .083" (14 GA)
R10270-SF
1280, 131N
131N-3-128KX
131N-40-1031
131N-28-357
CP153X
2.00" x .083" (14 GA)
R9553-SF
1 Used primarily in crank driven front mount hydraulic pump applications. Also suitable for clutch connection drives. Maximum operating speed 2800 rpm. (Not recommended for vehicular propeller shaft applications.)
