HOW TO MEASURE BRAKE DRUMS
Brake Surface Diameter
Bolt Circle Diameter
Brake Surface Width
Size of Bolt Holes
Overall Depth
Pilot Diameter
IDENTIFY REQUIRED DRUM BY MEASURING
Number of Bolt Holes - Slots in the back
Drilled and tapped holes
of the drum for wheel spoke clearance.
for skid control exciter.
CHECK THIS INFORMATION:
