48 / 69
KIT REF.
K122V
K123E
K123K K125E
K125G K125W K126W K127W K132K
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 9M12-1 2 10M55-2 2 10M35-5 2 10M35-3 2 9M16-6 2 10M18-2 2 10M18-2 2 10M18-2 2 10M35-5
BUSHING
2 20M24-2 4 20M19-9 4 20M19-9 4 20M19-9 4 20M16-7 2 20M18-1 2 20M18-1 2 20M18-1 4 20M19-9
2 20M18-2 2 20M18-2 2 20M18-2
STEEL LINER
2 31M18-1
2 31M16-2
TAPER LOCK PINS
2 60M1-16 2 60M1-23 2 60M1-9
2 60M2-8 2 60M2-8 2 60M2-8 2 60M1-23
2 60M1-17
END PLATE / PLUG
4 45P6-1 4 45P6-1 2 40P16 4 401.20.1 4 401.20.1 4 45P2-3 4 45P6-1
O-RING GASKET
2 92P1-24 2 93P1-12
4 93P1-12 2 41P4-1 4 92P1-4 4 92P1-4 4 92P1-4
2 92P1-25
BUSHING SEAL
2 91P7-1 4 91P1-29 4 91P1-29 4 91P1-29 4 91P3-1 4 91P1-44 4 91P1-44 4 91P1-44 4 91P1-29
2 91P8-1
BEARING
2 70P4-3 2 701.4.28 2 701.4.2 2 701.4.2 2 701.4.1 2 701.4.25 2 701.4.17 2 701.4.20 2 701.4.20
BEARING SEAL
2 91P2-11
SHIM
2 80P3-25 3
80P1-2 3 80P1-2 3 80P1-2 5 80P3-3 7 80P1-2 7 80P1-2 7 80P1-2 3 80P1-2
4 80P3-26 5
80P2-5 5 80P2-5 5 80P2-5 2 80P3-4 5 80P2-5 5 80P2-5 5 80P2-5 5 80P2-5
2 80P3-28 2 80P3-24 2 80P3-24 2 80P3-24 2 80P3-5
2 80P3-24
2 80P3-6
CAP SCREW
6 5/16-18X.5 12 1/4-20X1/2 12 1/4-20X1/2 12 1/4-20X3/4
NUT
4 50P19-2 2 50P19-2 2 50P19-1
2 50P19-1 2 50P19-1 2 50P19-1 2 50P19-2
LOCK WASHER
6
5/16
12
1/4
12
1/4
12
1/4
FELT WASHER
EXPANSION PLUG
2 45P1-8
RELIEF FITTING
4 90P1-1 4 90P1-1 4 90P1-1
COTTER PIN
2 102P16-3
2 102P16-1
LOCK RING
2 100P1-2
CASTLE NUT
2 50P14-1
KIT REF.
K139I
K140I
K140V
K141S
K146E
K146F
K146S
K147E
K148E
PART REF
QTY PART No. QTY PART No. QTY PART QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 10M24-1 2 10M16-13 2 9M14-1 2 10M38-6 2 10M35-2 2 10M21-15 2 10M43-1 2 10M55-1 2 10M55-1
BUSHING
4 20M17-1 4 20M17-1 2 20M21-17 4 20M21-10 4 20M18-8 4 20M18-1 4 20M18-6 4 20M18-8 4 20M18-8
STEEL LINER
2 31M20-1
TAPER LOCK PINS
2 60M2-11 4
602.4.1
4 60M2-19 2 60M1-9 2 60M1-25 2 60M2-19 2 60M1-16 2 60M1-16
2 60M1-17
2 60M1-26 2 60M2-20 2 60M1-17 2 60M1-17
END PLATE / PLUG
4 401.3.1 4
401.3.1
4 401.20.1
4 45P6-1
O-RING GASKET
4 92P1-8 4
92P1-8 2 92P1-34 4 92P1-21 4 93P1-12 4 92P1-4 4 92P1-20 4 93P1-12 4 93P1-12
2 92P1-40
BUSHING SEAL
4 91P3-1 4
91P3-1 2 91P1-50 4 91P1-34 4 91P1-36 4 91P1-44 4 91P1-38 4 91P1-36 4 91P1-36
2 91P8-2
BEARING
2 701.4.1 2
701.4.1 2 70P4-5 2 701.4.11 2 701.4.24 2 701.4.20 2 701.4.22 2 701.4.25 2 701.4.25
BEARING SEAL
2 91P2-2 2
91P2-2
2 91P2-4
SHIM
7 80P1-1 7
80P1-1 2 80P2-24 3 80P1-23 3 80P1-24 4 80P1-2 5 80P1-2 3 80P1-24 3 80P1-24
2 80P3-13 2 80P3-13 4 80P3-38 3 80P2-19 5 80P2-20 8 80P2-5 7 80P2-5 5 80P2-20 5 80P2-20
4 80P3-39 2 80P3-30 2 80P3-31
2 80P3-31 2 80P3-31
4 80P3-40
CAP SCREW
12 5/16-18X.7 12 5/16-18X.7
12 1/4-20 X 3/4
NUT
2 50P19-3
4 50P19-2 2 50P19-1 4 50P19-1 4 50P19-2 4 50P19-2 4 50P19-2
LOCK WASHER
12
5/16
12
5/16
12
1/4
FELT WASHER
EXPANSION PLUG
RELIEF FITTING
COTTER PIN
2 102P16-4
LOCK RING
CASTLE NUT
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 45
COMPONENTS
revision date 11/2012
KING PIN KIT COMPONENT PARTS
