STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 48
COMPONENTS
revision date 11/2012
KING PIN KIT COMPONENT PARTS
STEMCO Kaiser Qwik Kit
TM
KIT REF.
K71D
K71F
K72F
K75F
K75M K76F
K80A
K80G
K80R
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 10M2-1 2 10M13-6 2 10M37-4 2 10M25-1 2 10M13-7 2 10M25-1 2 10M63-2 2 10M42-4 2 10M52-2
BUSHING
4 20M2-1 4 20M13-4 4 20M13-7 4 20M14-6 4 32A16-12 4 20M14-6 4 32A18-5 2 20M16-11 4 20M15-7
STEEL LINER
TAPER LOCK PINS
4 602.4.1 2 60M2-17 2 60M1-10 2 60M1-1 2 60P6-1 2 60M1-1 4 60M1-21
2 60M1-14
2 60M1-11 2 60M1-2
2 60M1-2
2 60M1-7
END PLATE / PLUG
4 401.143.1
2 401.128.1 4 401.138.1 4 45P2-5 4 45P8-4
O-RING GASKET
4 92P1-16 4
45P2-4 4 45P2-4 2 92P1-4 4 92P1-23
4 92P1-37 2 41P10-1
BUSHING SEAL
4 91P1-43 4 91P1-35 4 91P1-35 4 91P1-16 4 91P1-37 4 91P1-16 4 91P1-47 2 91P5-1 4 91P1-41
2 91P6-1
BEARING
2 701.4.4 2 70P2-15 2 701.4.23 2 701.4.5 2 70P2-14 2 701.4.5 1 701.4.31 2 70P4-2A 2 701.4.5
1 701.7.1 2 70P4-2B
BEARING SEAL
2 91P2-16
2 91P2-14
2 91P2-15
SHIM
5 80P1-4 5 80P1-12 5 80P2-10 5 80P1-5
5 80P1-5 6 80P2-5 8 80P1-26 5 80P1-25
5 80P2-1 5 80P2-10
5 80P2-2
5 80P2-2 12 80P3-24 4 80P2-22 5 80P2-21
CAP SCREW
8 5/16-18X3/4
6 5/16-18X3/4
NUT
2 50P19-1 4 50P19-1 4 50P19-1 2 M10X1.5 4 50P19-1 4 50P19-1
4 50P19-1
LOCK WASHER
8
5/16
6
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-11
RELIEF FITTING
2 90P1-1
COTTER PIN
LOCK RING
2 100P1-3 4 100P1-3
4 100P1-5
CASTLE NUT
2 50P17-1
KIT REF.
K901L
K921L
K931L
K941F
K941FA K941R K942F
K942FA K95F
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 10M21-1 2 10M21-2 2 10M21-3 2 10M33-2 2 10M33-2 2 10M52-1 2 10M33-2 2 10M33-2 2 10M26-1
BUSHING
4 20M19-5 4 20M20-1 4 20M20-1 4 20M20-1 4 20M20-1 4 20M15-5 4 20M20-1 4 20M20-1 4 20M16-7
STEEL LINER
TAPER LOCK PINS
2 60M7-3 2
60M7-3 2 60M1-1 2 60M1-1 2 60M1-1 2 60M1-7 2 60M1-1 2 60M1-1 2 60M1-1
2 60M7-4 2
60M7-4 2 60M1-2 2 60M1-2 2 60M1-2 2 60M1-14 2 60M1-2 2 60M1-2 2 60M1-2
END PLATE / PLUG
2 401.128.1 4 401.128.1 4 401.128.1 4 401.128.1 4 401.128.1 4 401.139.1 4 45P2-3 4 45P2-3 2 401.128.1
O-RING GASKET
4 92P1-4 4
92P1-4 4 92P1-4 4 92P1-4 4 92P1-4 4 92P1-26
2 92P1-4
BUSHING SEAL
4 91P1-29 4
91P1-6 4 91P1-29 4 91P1-29 4 91P1-29 4 91P1-41 4 91P1-29 4 91P1-29 4 91P3-1
BEARING
2 701.4.2 2
701.4.2 2 701.4.27 2 701.4.2 2 701.4.20 2 701.4.5 2 701.4.2 2 701.4.20 2 701.4.1
BEARING SEAL
2
91P2-1
2 91P2-15
SHIM
5 80P1-2 5
80P1-2 5 80P1-2 9 80P1-2 9 80P1-2 5 80P2-21 9 80P1-2 9 80P1-2 9 80P1-1
8 80P2-5 8
80P2-5 8 80P2-5 9 80P2-5 7 80P2-5
7 80P2-5 7 80P2-5
CAP SCREW
12 5/16-18X3/4 12 5/16-18X3/4 12 5/16-18X3/4 12 5/16-18X3/4 12 5/16-18X3/4 12 5/16-18X1
6 5/16-18X3/4
NUT
4 50P19-2 4 50P19-2 4 50P19-1 4 50P19-1 4 50P19-1 4 50P19-1 4 50P19-1 4 50P19-1 4 50P19-1
LOCK WASHER
12
5/16
12
5/16
12
5/16
12
5/16
12
5/16
12
5/16
6
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-9
2 45P1-8
RELIEF FITTING
2 90P1-1
2 90P1-1
COTTER PIN
LOCK RING
2 100P1-1
2 100P1-2
CASTLE NUT
