COMPONENTS
revision date 11/2012
KING PIN KIT COMPONENT PARTS
STEMCO Kaiser Plus Kit
TM
KIT REF.
70.095.06 70.095.07 70.096.06 70.098.09 70.101.09 70.102.09 70.103.19 70.119.09 70.120.05
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 105.26.1 2
95.16.7 2 105.26.1 2 105.12.3 2 105.13.1 2 105.37.1 2 105.56.1 2 105.16.2 2 105.24.10
BUSHING
4 202.16.7 2 202.14.1 4 202.16.7 4 202.12.3 4 202.13.1 4 202.13.1 4 202.13.1 4 202.17.1 4 202.16.9
2 202.14.2
STEEL LINER
2 312.16.4
TAPER LOCK PINS
2 60M1-1
2 60M1-1 2 60M7-1 2 60M7-1 2 60M4-10 4 60M2-20 4 602.4.1 2 60M2-15
2 60M1-2
2 60M1-2
2 60M4-11
2 60M4-7
END PLATE / PLUG
4 45P2-5
4 401.129.1
O-RING GASKET
2 41P7-1 2
41P4-1
4 41P3-3 4 92P1-16 4 92P1-16 4 92P1-28 4 92P1-15 4 41P5-2
BUSHING SEAL
4 91P3-1
4 91P3-1
4 91P1-14 4 91P1-14 4 91P1-14
4 91P1-25
BEARING
2 701.4.1 2
701.4.5 2 701.4.1 2 701.4.4 2 701.4.15 2 701.4.15 2 701.4.15 2 701.4.1 2 701.4.19
BEARING SEAL
2 91P2-3 2 91P2-3 2 91P2-3
SHIM
9 80P1-1 9
80P2-9 9 80P1-1 5 80P1-4 4 80P1-22 5 80P1-22 5 80P1-22 7 80P1-1 5 80P1-14
2
80P3-7
5 80P2-1 4 80P2-18 5 80P2-18 5 80P2-18
5 80P2-11
2
80P3-9
CAP SCREW
12 5/16-18X1
NUT
4 50P19-1
4 50P19-1 2 50P19-2 2 50P19-2 2 50P19-2 4 50P19-2
2 50P19-3
LOCK WASHER
12
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-8 2 45P1-11
RELIEF FITTING
COTTER PIN
2 102P16-1
LOCK RING
2 100P1-2 2 100P1-3
CASTLE NUT
2 50P14-3
KIT REF.
70.120.09 70.120.18 70.120.95 70.120.99 70.121.05 70.121.07 70.122.05 70.122.95 70.123.05
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 105.38.2 2 105.33.3 2 105.24.10 2 105.38.2 2 105.24.10 2 105.21.8 2 105.35.3 2 105.35.3 2 105.55.2
BUSHING
4 202.21.11 4 202.20.1 4 202.16.8 4 201.21.13 4 202.16.9 4 202.19.8 4 202.19.10 4 202.19.9 4 202.19.10
STEEL LINER
TAPER LOCK PINS
2 60M2-19 2
60M1-1 2 60M2-15 2 60M2-19 2 60M2-15 2 60M4-7 2 60M1-9 2 60M1-9 2 60M1-16
2 60M2-20 2
60M1-8
2 60M2-20
2 60M4-8
2 60M1-17
END PLATE / PLUG
4 401.128.1 4 401.129.1
4 401.129.1 4 401.128.1
O-RING GASKET
4 92P1-20 4
92P1-4 4 41P5-2 4 92P1-20 4 41P5-2 4 92P1-4 4 93P1-12 4 93P1-12 4 93P1-12
BUSHING SEAL
4 91P1-32 4 91P1-29 4 91P1-25 4 91P1-32 4 91P1-25
4 91P1-29 4 91P1-29 4 91P1-29
BEARING
2 701.4.21 2 701.4.27 2 701.4.19 2 701.4.21 2 70P2-13 2 701.4.18 2 701.4.2 2 701.4.2 2 701.4.28
BEARING SEAL
2 91P2-9/10
SHIM
6 80P1-23 5 80P1-19 5 80P1-14 6 80P1-23 5 80P1-14 5 80P1-2 3 80P1-2 3 80P1-2 3 80P1-2
6 80P2-19 3 80P2-15 5 80P2-11 6 80P2-19 5 80P2-11 5 80P2-5 5 80P2-5 5 80P2-5 5 80P2-5
4 80P3-30 4 80P3-33
4 80P3-30
4 80P3-24 4 80P3-24 2 80P3-24
CAP SCREW
12 5/16-18X1 12 5/16-18X1 12 5/16-18X1 12 5/16-18X1 12 5/16-18X1
NUT
4 50P19-2 4 50P19-1 2 50P19-3 4 50P19-2 2 50P19-3
2 50P19-1 2 50P19-1 4 50P19-2
LOCK WASHER
12
5/16
12
5/16
12
5/16
12
5/16
12
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-16
RELIEF FITTING
COTTER PIN
LOCK RING
2 100P1-7
CASTLE NUT
