STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 49
COMPONENTS
revision date 11/2012
KING PIN KIT COMPONENT PARTS
STEMCO Kaiser Qwik Kit
TM
KIT REF.
K95G
K961L
K96F
K970R K971R K981R
K98I
KD900R KD901R
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 9M16-7 2 10M21-3 2 10M26-1 2 10M16-5 2 10M16-7 2 10M21-12 2 10M12-3 2 9M16-10 2 10M14-1
BUSHING
2 20M14-1 4 20M20-1 4 20M16-7 4 20M16-7 4 20M16-7 4 20M19-9 4 20M12-3 4 20M14-6 4 20M14-6
2 20M14-2
STEEL LINER
2 31M16-4
2 31M16-8
TAPER LOCK PINS
2
60M1-7 2 60M1-1 4 602.4.1 4 602.4.1 2 60M1-7 2 60M7-1
4 602.4.1
2
60M1-8 2 60M1-2
2 60M1-8
END PLATE / PLUG
2
40P16
4 401.128.1 4 45P2-5 2 40M123-1 4 401.128.1 4 45P2-3 4 40M120-4 2 40P16 2 401.128.1
O-RING GASKET
2 41P4-1 4
92P1-4
2 92P1-8 4 92P1-4
4 93P1-1 2 41P4-1 2 92P1-4
BUSHING SEAL
4 91P1-29 4 91P3-1 4 91P3-1 4 91P3-1 4 91P1-29
4 91P1-16
BEARING
2 701.4.5 2 701.4.27 2 701.4.1 2 701.4.1 2 701.4.1 2 701.4.27 2 701.4.4 2 701.4.5 2 701.4.5
BEARING SEAL
2 91P2-7
SHIM
9 80P2-9 5
80P1-2 9 80P1-1 13 80P1-1 7 80P1-1 5 80P1-19 5 80P1-4 9 80P2-9 5 80P1-5
2 80P3-7 5
80P2-5
5 80P2-15 5 80P2-1 2 80P3-7 5 80P2-2
2 80P3-9
2 80P3-9
CAP SCREW
6 1/4-28X1/2 12 5/16-18X3/4
4 5/16-18X3/4 12 5/16-18X3/4
8 1/4-28X5/8 6 5/16-18X1/2 6 5/16-18X3/4
NUT
4 50P19-1 4 50P19-1
4 50P19-1 2 50P19-2
LOCK WASHER
6
1/4
12
5/16
4
5/16
12
5/16
8
1/4
6
5/16
6
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-11
2 45P1-8
2 45P1-11 2 45P1-11
RELIEF FITTING
2 90P1-3
4 90P1-3
2 90P1-1
COTTER PIN
2 102P16-1
2 102P16-1
LOCK RING
2 100P1-3
2 100P1-2
2 100P1-2 2 100P1-13
CASTLE NUT
2 50P14-3
2 50P14-3
KIT REF.
KE350F KG931R KH901L KH931L KH946R
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 10M10-3 2 10M21-3 2 10M22-1 2 10M22-2 2 10M21-14
BUSHING
4 20M5-2 4 20M20-1 4 20M21-1 4 20M21-2 2 20M19-9
2 20M19-11
STEEL LINER
TAPER LOCK PINS
2 60M2-3 2
60M1-1 4 60M4-4 2 60M1-3 2 60M1-3
2
60M1-2
2 60M1-4 2 60M1-4
2
60M1-8
2 60M1-8
END PLATE / PLUG
2 45P2-2 4 401.128.1 2 401.128.2 4 401.128.2 4 45P7-1
O-RING GASKET
4
92P1-4 2 92P1-9 4 92P1-9
BUSHING SEAL
4 91P1-23 4 91P1-29
4 91P1-15 4 91P1-29
BEARING
2 70P2-3 2 701.4.20 2 701.4.11 2 701.4.11 2 701.4.27
BEARING SEAL
2 91P2-11
2 91P2-4
SHIM
5 80P1-10 5
80P1-2 5 80P1-9 5 80P1-9 10 80P1-2
5 80P2-8 8
80P2-5 9 80P2-7 9 80P2-7 10 80P2-5
2 80P3-29
2 80P3-34
CAP SCREW
12 5/16-18X3/4 6 5/16-18X3/4 12 5/16-18X3/4
NUT
2 50P19-1 4 50P19-1
4 50P19-1 4 50P19-1
LOCK WASHER
12
5/16
6
5/16
12
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-10
RELIEF FITTING
2 90P1-1
COTTER PIN
LOCK RING
2 100P1-5
CASTLE NUT
