STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 54
COMPONENTS
revision date 11/2012
KING PIN KIT COMPONENT PARTS
STEMCO Kaiser Econo Kit
TM
www.stemcokaiser.com
KIT REF.
50.040.06 50.050.04 50.051.07 50.053.06 50.055.07 50.056.07 50.070.04 50.070.07 50.070.18
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 105.9.2 2
105.3.1 2 105.11.9 2 105.50.3 2 105.11.10 2 105.11.10 2 105.2.1 2 105.12.1 2 105.52.3
BUSHING
4 201.9.2 2 201.11.4 4 201.11.3 4 201.2.3 4 201.11.7 4 201.11.10 4 201.2.1 4 201.12.1 4 201.15.7
2 201.11.5
STEEL LINER
TAPER LOCK PINS
2 60M2-6 4
60M2-7 2 60M3-1 2 60M2-3 2 60M1-15 2 60M1-15 4 602.4.1 2 60M3-1 2 60M1-14
2 60M1-7
END PLATE / PLUG
4 40M11-1
O-RING GASKET
4 41P3-8
4 41P3-6 4 92P1-19 4 41P3-6 4 41P3-6 2 41P3-4 4 41P3-1
BUSHING SEAL
4 91P1-45 4 91P1-42
4 91P1-41
BEARING
2 701.4.10 2
701.4.9 2 701.2.1 2 701.4.4 2 701.4.14 2 701.4.19 2 701.4.4 2 701.4.4
BEARING SEAL
2 91P2-15
SHIM
5 80P1-8 5 80P1-10 5 80P1-6 5 80P1-4 7 80P1-21 7 80P1-21 5 80P1-4 5 80P1-21 5 80P1-25
5 80P2-6 5
80P2-8 5 80P2-3 5 80P2-1 5 80P2-17 5 80P2-17 5 80P2-1 5 80P2-17 5 80P2-21
CAP SCREW
8 10-32X3/8
4 5/16-18X3/4
NUT
2 50P19-1 4 50P19-2 2 50P19-2 2 50P19-1 2 50P19-2 2 50P19-2
2 50P19-2 4 50P19-1
LOCK WASHER
8
10/32
4
5/16
FELT WASHER
EXPANSION PLUG
4
45P1-4
2 45P1-6
RELIEF FITTING
2 90P1-3
COTTER PIN
LOCK RING
2 100P1-4
CASTLE NUT
KIT REF.
50.071.04 50.071.06 50.071.96 50.072.06 50.073.06 50.075.06 50.076.06 50.080.18 50.095.06
PART REF
QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No. QTY PART No.
KING PIN
2 105.2.1 2 105.13.6 2 105.13.6 2 105.37.4 2 105.50.2 2 105.25.1 2 105.25.1 2 105.52.2 2 105.26.1
BUSHING
4 201.2.1 4 201.13.4 4 201.13.6 4 201.13.7 4 201.2.7 4 201.14.6 4 201.14.6 4 201.15.5 4 201.16.7
STEEL LINER
TAPER LOCK PINS
4 602.4.1 2 60M2-17 2 60M2-17 2 60M1-10 2 60M2-3 2 60M1-1 2 60M1-1 2 60M1-14 2 60M1-1
2 60M1-11
2 60M1-2 2 60M1-2 2 60M1-7 2 60M1-2
END PLATE / PLUG
4 401.143.1 4
45P2-4 4 45P2-4 4 45P2-4
4 45P2-5
O-RING GASKET
4 92P1-16
4 92P1-19 2 41P7-1
2 41P7-1
BUSHING SEAL
4 91P1-43 4 91P1-35 4 91P1-35 4 91P1-35
4 91P1-16 4 91P1-16 4 91P1-41 4 91P3-1
BEARING
2 701.4.4 2 70P2-15 2 70P2-15 2 701.4.23 2 701.4.4 2 701.4.5 2 701.4.5 2 701.4.5 2 701.4.1
BEARING SEAL
2 91P2-16
2 91P2-15
SHIM
5 80P1-4 5 80P1-12 5 80P1-12 5 80P2-10 5 80P1-4 5 80P1-5 5 80P1-5 5 80P1-25 9 80P1-1
5 80P2-1 5 80P2-10 5 80P2-10
5 80P2-1 5 80P2-2 5 80P2-2 5 80P2-21
CAP SCREW
8 5/16-18X3/4
NUT
2 50P19-1 2 50P19-1 4 50P19-1 2 50P19-1 4 50P19-1 4 50P-19-1 4 50P19-1 4 50P19-1
LOCK WASHER
8
5/16
FELT WASHER
EXPANSION PLUG
2 45P1-11
2 45P1-8
RELIEF FITTING
2 90P1-3
COTTER PIN
LOCK RING
2 100P1-3
2 100P1-2
CASTLE NUT
