HEADLAMPS - FOG & DRIVING
SPE
• Includes illuminated rocker
switch, #192 40 amp
relay, 15 amp fuse in-line,
connectors, and 20 feet of
16 ga. wire
80593 Wiring kit
• On-off switch for use with
auxiliary lights and heated
mirrors
80594 Illuminating rocker switch
• Recommended for use
where heavy amp draw is
required
• Includes 20 ft. of 14 gauge
wire, connectors, mounting
hardware & wiring diagram
125
70 amp heavy duty relay kit
• 12 volt, 55 Watt, H-3
• 115 candlepower, 4.5 amp
• For use on fog & driving lights
80571 Halogen bulb, retail pack
• 12 volt, 100 Watt, H-3
• 187 candlepower, 8.0 amp
• For use on off-road lights only
80560 Halogen bulb, retail pack
•
24 volt, 70 Watt, H-3, 3.0 amp
• For use in auxiliary & emergency lamps
80561 Halogen bulb
• 36 volt, 45 Watt, H-3, 1.2 amp
• For use in material handling industry
Heavy Duty Relays
Four Terminals
Five Terminals
Five Terminals
194, 195
190, 191, 1924
(uses 9185 connector)
192D
(uses 9185 connector)
Halogen Bulbs
80571
Halogen Bulbs
• 12 volt, 55 Watt, H-1, 4.5
amp
• Popular beacon & lightbar
replacement
• For use with units 331A,
332A, 334A, 360A, 360W,
365A
80563 Halogen bulb, retail pack
80563
• These relays replace both
Hella and Bosch units.
190
40 A, 12V, 5 terminal,
(no tab), w/diode protection
(switched outputs)
191
40 A, 12V, 5 terminal, (no tab)
192
40 A, 12V, 5 terminal
1924 20 A, 24V, 5 terminal
194
40 A, 12V, 4 terminal
195
70 A, 12V, 4 terminal
9185 Relay connector w/12”
length of 12 gauge wiring
192
9185
Long Life
Halogen Bulbs
• Ideal for everyday and heavy duty
conditions
• For use in dual headlamp systems
• Emits white light
• DOT compliant
• 12 volt
• Lasts 6 times longer than standard halogen bulb
Note: It is recommended that replacement should be made in pairs
for maximum halogen headlamp lighting benefits.
80596 Halogen hi/low beam, HB2, 60/55 watts
80596 80597
Halogen Bulbs
• 12 volt, 50 Watt, 108 CP, 4.0 amp
• Bayonet style bulb replaces 1156 bulb for
high powered off-road back-up lamps
• Can also be used in place of 1195 bulb to
double the output of emergency warning lamps
(i.e., 315, 335 series lamps)
• For use with 9682, 9683, 331A, 332A
80564 Halogen bulb, retail pack
80564
Accessories
80593
80594
125
