137 / 348
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
135
SPE
BUS LAMPS
91243Y
91244R
91242R
91
®
Series
Stop, Turn & Tail
Front Park & Turn
Sealed
Material:
• Polycarbonate lens &
housing
• 16 gauge wire
Light Source:
• Heavy duty shock mount
bulb
• 12v designed at 12.8v,
2.1/0.48 amp, 32/2 cp
• 24v designed at 24v,
0.93/0.34 amp, 32/6 cp
Kit Components:
91002R/Y lamp kits:
1 - 91202R/Y lamp
1 - 94993 plug
Recommended Accessories:
• 97031 mounting gasket
7.00
1.30
PN 91242R
LED
91
®
Series
Stop, Turn & Tail &
Rear Turn Lamps
47 Diode
Hard Wired
Material
• Acrylic lens
• ABS housing
• 18 gauge wire
Light Source:
• Designed at 13.5v
0.55 - 0.07 amp stop/turn
0.03 - 0.04 amp tail
0.60 - 0.70 yellow
Recommended Accessories:
• 97039 gasket
• Popular in bus applications
• Features over-voltage & spike protection circuitry
• Mounts in any 360˚ application
91244R Stop, turn & tail lamp, red
91243Y Rear turn lamp, yellow
91242R Stop, turn & tail lamp w/reflex, red
91241Y Rear turn lamp w/reflex, yellow
7.02
6.25
1.92
1.70
See Above
91002R Stop, turn & tail lamp kit, red
91002Y Front park & turn lamp kit, yellow
91202R Stop, turn & tail lamp, red
91202Y Front park & turn lamp, yellow
• Contains a heavy duty shock mount
12 volt dual filament bulb
• Mounting gasket provides additional
protection between lamp & body
• Mounts in a 5.375” hole
• Replaces Signal-Stat 6510/A
0.20 screw hole diameter
6.281 bolt hole circle
