139 / 348
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
137
SPE
BUS LAMPS
Bus Products
Sealed
Material:
• Polycarbonate lens & housing
• Nylon bulb mount
• 24 gauge bulb wire
• 18 gauge plug wire
Light Source:
• 12v dual filament baseless
bulb
• 12v lamp designed at
12.8v/14.0v, 2.10/.48 amp &
32/2 cp
Bus Products
Bulb Replaceable
Material:
• Polycarbonate lens &
housing
• Vinyl & rubber bulb socket
• 16 gauge wire
Light Source:
95415 S/T socket
• Bulb: #3157, wedge base
• Designed at 12.8v, 2.10 amp & 32 cp
95407 S/T/T socket
• Bulb: #3157, wedge base
• Designed at 12.8v/14.0v, 2.10/.48
amp & 32/2 cp
7.38"
1.88"
6.75" DIA
Combination
Bulb Replaceable
Material:
• Acrylic lens
• Steel base
• 16 gauge wire
Light Source:
• Bulb: #1156, one wire
• Bulb: #1157, two wire
Replacement Parts:
• 9384A yellow lens for 6501A
Arrow T/S Products
Bulb Replaceable
Material:
• Acrylic lens
• Steel base w/black epoxy
• Black foam gasket
• 16 gauge wire
Light Source:
• Bulb: #1156
• Designed at 12.8v, 2.10 amp
& 32 candlepower
Replacement Parts:
• 99167Y yellow lens w/arrow
• 9520 lens gasket
• 9521 mounting pad
• 99168R red lens for 6503
• 99168Y yellow lens 6503A
• 90325Y lamp functions as a turn signal & features a
directional arrow
• Surface mounts with four #10 screws on a 6.25” bolt circle
• Requires a 1” diameter hole, 1” deep
• Popular lamp on buses & emergency vehicles
• Replaces Signal-Stat 6505/A
90325Y Turn signal lamp w/arrow, yellow
6503 Turn signal lamp, red
6503A Turn signal lamp, yellow
90325Y
6503
6.25
7.12
2.00
• Popular school bus signal lamps
• Rimless lens construction
• Positive seal prevents leaking and eliminates cracked lenses
• Double optic lens covers black enameled steel housing
6500 Red, one wire, turn signal
6500A Amber, one wire turn signal
6501 Red, one wire arrow lamp
6501A Amber, one wire arrow lamp
6502 Red, two wire S/T/T
6500
6501A
6.460
2.030
5.220
4.740
4.200
3.000
.218screwholediameter
6.460
2.030
5.220
4.740
4.200
3.000
.218screwholediameter
• Watertight lamp mates w/Packard connector
• Direct replacement for GMC buses
• Recess mounts using two screws at 3.0” centers & two
screws at 4.2” centers
• 12v lamps mate with P.E. Connector 62884715
07080
Lamp, yellow 07081 Lamp, red
07082C Lamp, clear
• Bulb socket cams-in for ease of repair/ replacement
(sold separately)
• Recess mounts using two screws at 3.0” centers &
two screws at 4.2” centers
07098
Lens/housing, red
95415
S/T socket
95407
S/T/T socket
