Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
139
SPE
BUS LAMPS
• Surpasses 2,000 hours of incandescent
bulbs by nearly 50x
• 60% lower power consumption than
“incandescent lamps, allowing more power
for other vehicle requirements
• Electronics fully sealed in epoxy, to resist
against corrosion & moisture
3.81
1.50
1.56
1.81
2.34
1.59
26353Y & 26723
• Surface mounts on two screws at
• 1.5” centers
• Ground through base
• Popular for use on school & commercial buses
• Heavy duty steel & acrylic construction
• Lens attaches to base with one center screw
• Optional zinc-plated steel guard provides
additional protection
• Replaces Signal-Stat 1151/1151A/9251
26353R Lamp only, red
26353Y Lamp only, yellow
26723
Steel guard
Marker Products
Bulb Replaceable
Material:
• Acrylic lens
• Steel base
• Rubber gasket
Light Source:
• Bulb: #168
• Designed at 14.0v, 0.35 amp
& 3 cp
Replacement Parts:
• 99170R red lens
• 99170Y yellow lens
5.79"
2.88"
5.79"
2.88"
.96"
1.75"
.197"MIN MOUNTINGHOLELOCATIONS
4.75"
LED Dome Lamp
6 Diodes
Material:
• Clear Polycarbonate Lens
• Steel Housing
Light Source:
• 6 Light Emitting Diodes (LEDs)
• Designed at 13.5v, .40 amps
Recommended Accessories:
• 97301 clear lens
80162C Lamp w/blunt cut wire
80164C Lamp w/.180 bullet connectors
3.000
6.810
6.000
1.500
.37
See Above
Interior/Dome
Products
Bulb Replaceable
Material:
• Acrylic lens
• Steel base
Light Source:
• Bulb: #93
• Designed at 12.8v,
1.04 amp & 15 cp
Replacement Parts:
• 99172 clear lens
• Flush mounts on two screws at 6.0” centers
• Requires a 2” x 5-1/4” hole
• Grounds through mounting screws
• Functions as an interior dome, a compartment, or a
utility lamp
• Heavy-duty steel & acrylic construction
81350
Lamp only
0.180 SCREW HOLE DIAMETER
