LED STROBES & BEACONS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
145
WAR
7.750"
8.687"
7.000"
3.500"
Ø
0.625"
LED
& Gas Discharge
Strobes
Multi Flash
Class 1 & 2
Material:
• Acrylic cover
• Polycarbonate lens
• Aluminum base
• 18 gauge wire
Gas Discharge Light Source:
• Joules: 11 (single) 15.5 (double)
17.6 (quad)
• Amps: 2 at 12v
• Voltage: 12-24v
• Flash Rate: 80 SFSPM, 65
DFSPM,65 QFSPM
• Class: 1 quad & double flash
• Class: 2 single flash
LED Light Source:
• Amps: 0.6 at 12v, 0.3 at 24v
• Voltage: 12-24v
• Class: 1
Replacement Parts:
• 92725 strobe tube
• Field selectable flash patterns via
internal jumper single, double,
quad flash
• LED diagnostic indicator
• Clear dust cover seals out dirt & for
easy cleaning
• Modular circuit is completely
encapsulated for increased shock &
weather resistance
• Mounts easily with two toggle bolts on
3-1/2” centers
• 24 customer selectable flash patterns
• High/Low intensity feature (manual
& automatic)
• LED version covered by 5-year
limited warranty
92865Y
92865Y LED permanent mount lamp, yellow
92513Y Permanent mount lamp, yellow
92513C Permanent mount lamp, clear
4.625" DIA
3.50"
5.125"
Signal-Stat
®
4.25
4.25
LED
& Gas Discharge
Strobes
Multi Flash Class 3
Material:
• Polycarbonate lens
• ABS base
• 18 gauge wire
Light Source:
• Joules: 1.5 (strobe)
• Amps – .5 at 12v (strobe) .35
(LED)
• Voltage: 12-72v (strobe)
10-16v (LED)
• Class: 3 LED
Replacement Parts:
• 92711 strobe tube
• Low profile strobe ideal for many applications
• Twist on/off lens
• LED version offers 29 selectable flash patterns
• Fully encapsulated LED circuitry ensures
trouble free operation
300A LED permanent mount lamp, yellow
301A LED magnetic mount lamp, yellow
307A Permanent mount lamp, yellow
307B Permanent mount lamp, blue
307R Permanent mount lamp, red
Gas Discharge
Mini Strobes
Quad Flash Class 3
Material:
• Polycarbonate lens
• ABS base
• 18 gauge wire
Light Source:
• Joules: 3.75
• Amps – .5
• Voltage: 12v
• Flash rate 65 QFSPM
• Class: 3
Replacement Parts:
• 92711 flash tube
• Modular components & encapsulated circuitry
make for quick repairs & minimize downtime
• Quick snap on lens
• Mounts with 1/2” conduit pipe & includes
knockouts for permanent surface mounting
• Review installation instructions & warning
labels for proper use
92534C Permanent mount lamp, clear
92534Y Permanent mount lamp, yellow
92539Y Magnetic mount lamp, yellow
