LED STROBES & BEACONS
WAR
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
144
Signal-Stat
®
Gas Discharge Strobes
Multi Flash
Class 1 & 2
Medium & Low Profile
Material:
• Polycarbonate lens
• Metal base
Light Source:
• Joules: 11 (single)
15.5 (double) 17.6 (quad)
• Amps: 2 @ 12v
• Voltage: 12 – 24v
• Flash Rate: 80 SFPM, 65
DFPM, 65 QFPM
• Class 1 quad & double flash
• Class 2 single flash
Replacement Parts:
• 99220Y/B/R/W medium profile
lens
• 99221Y/B/R/W low profile lens
• 92725 strobe tube
• Field selectable flash patterns via internal jumper single,
double, quad flash
• LED diagnostic indicator
• Twist on/off lens
• High/Low intensity feature (manual & automatic)
• Designed for surface & pipemount (1” NPT pipe thread)
6810A
6.40"
4.75"
Low Profile
6.40"
6.70"
Medium Profile
6.40"
4.75"
Low Profile
6.40"
6.70"
Medium Profile
LED
& Gas Discharge
Strobes
Multi Flash Class 1 & 2
Medium & Low Profile
Material:
• Polycarbonate lens & housing
• 18 gauge wire
Gas Discharge Light Source:
• Joules: 11 (single) 15.5 (double)
17.6 (quad)
• Amps: 2 at 12v
• Flash Rate: 80 SFPM, 65 DFPM,
65 QFPM
• Class: 1 quad & double flash,
2 single
LED Light Source:
• Amps: 0.6 at 12v, 0.3 at 24v
• Class: 1 medium profile, 2 low profile
Replacement Parts:
• 99220Y/B/R/W medium profile lens
• 99221Y/B/R/W low profile lens
• 92726 gas discharge strobe tube
Low Profile Lamps
6810B Permanent mount, blue
6810R Permanent mount, red
6810W Permanent mount, clear
6810A Permanent mount, yellow
Medium Profile Lamps
6811B Permanent mount lamp, blue
6811R Permanent mount lamp, red
6811A Permanent mount, yellow
6811MA Magnetic mount, yellow, 12 V
• Field selectable flash patterns via internal
jumper single, double, quad flash
• LED diagnostic indicator
• Modular circuit is completely encapsulated for
increased shock & weather resistance
• Twist on/off lens
• High/Low intensity feature (manual &
automatic)
• Designed for surface & pipemount (1” NPT
pipe thread)
• LED version covered by 5-year limited warranty
Low Profile Lamps
92862Y LED permanent mount, yellow
92863Y LED magnetic mount, yellow
6600R Permanent mount, red
6600W Permanent mount, clear
6600A Permanent mount, yellow
6600MA Magnetic mount, yellow, 12 V
Medium Profile Lamps
92860Y LED permanent mount, yellow
92861Y LED magnetic mount, yellow
6601B Permanent mount, blue
6601R Permanent mount, red
6601W Permanent mount, clear
6601A Permanent mount, yellow
6601MA Magnetic mount, yellow, 12 V
92862Y
92863Y
92860Y
