LED STROBES & BEACONS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
143
WAR
• Excellent option for city/county
municipal, cement mixer,
heavy-duty construction or off-road
applications
• Offers single, dual,quad flash patterns
• Innovative optic design keeps exterior
lens free of optics, for ease of
maintenance & cleaning
• Rugged black powder coated corrosion-
resistant die-cast aluminum base
• Designed for surface mount as well as
pipe mount (1” NPT pipe thread)
• Threaded lens design does not require
tool to replace lens
• Built-in LED diagnostic indicator shows
operational state of the lamp assembly
• Electronics are encapsulated in epoxy to
protect against damage caused by
moisture & corrosion
• Mounting gasket & #10 installation
screws included
6.8"
Gas Discharge
Strobe Class 1
Medium Profile
Material:
• Polycarbonate lens
• Die cast aluminum housing
• Blunt cut 18 gauge wire
Light Source:
• Operational at 10v - 30v
12v current draw - 2.0 amps
24v current draw - 1.0 amps
• Meets SAE J1318 Class 1 legal
functions with dual & quad flash
patterns
• Meets SAE J1318 Class II legal
functions
with single flash pattern
• Operates from -30˚F to 135˚F
Replacement Parts:
• 92725 strobe tube
Recommended Accessories:
• 92545 guard
Mounts on 6.1” dia., 120˚ holes
6.25
6.00
3.50
5.50
LED
& Gas Discharge Strobes
Class 1 & 2, Medium Profile
Material:
• Polycarbonate lens
• Die cast aluminum base
• 18 gauge wire
Gas Discharge Light Source:
• Joules: 11 (single) 15.5 (double) 17.6 (quad)
• Amps: 2 at 12v
• Voltage: 12-24v
• Flash Rate: 80 SFPM, 65 DFPM, 65 QFPM
• Class: 1 quad & double flash, Class: 2 single flash
LED Light Source:
• Amps: 0.6 at 12v, 0.3 at 24v
• Class: 1
Replacement Parts:
• 99146C clear lens
• 92725 strobe tube
• 92713 power supply
• LED version meets SAE Class 1 & California 13
• Field selectable flash patterns via internal
jumper single, double, quad flash
• LED diagnostic indicator
• Modular circuit is completely encapsulated for
increased shock & weather resistance
• 24 customer selectable flash patterns
• High/Low intensity feature (manual or automatic)
• LED version covered by 5-year limited warranty
92864Y LED permanent mount lamp, yellow
92516Y Permanent mount lamp, yellow
92864Y
92592Y Permanent mount lamp, yellow
