FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
20
80
®
Series
Stop/Turn/Tail
Bulb Replaceable
Material:
• Black painted steel or
stainless steel housing
• Polycarbonate lens
• Steel retaining ring
Light Source:
• Bulb: #1157
Replacement Parts:
• 99008R red lens
• 97093 mounting gasket
• 97094 lens gasket
• 97945 steel retaining ring
FMVSS:
• I6,S2,P
80
®
Series
Stop/Turn/Tail &
Front/Park/Turn
Bulb Replaceable
Material:
• Black plastic housing
• Acrylic lens
• Steel retaining ring
Light Source:
• Bulb: #1157
Replacement Parts:
• 99007R red lens
• 97945 retaining ring
FMVSS:
• Red - I6,S2,T
• Yellow - I6,P
• Clear - (2)R
80
®
Series
Stop/Turn/Tail
Bulb Replaceable
Material:
• Rubber housing
• Polycarbonate lens
Light Source:
• Bulb: #1157
Replacement Parts:
• 99008R red lens
FMVSS:
• I6,S2,T
• Mounts flush to vehicle
• Retaining ring allows for easy
bulb replacement
0.20 screw hole diameter
5.00 bolt hole circle
4.43 mounting hole
1.62
5.38
4.38
80334R Red w/black housing
80335R Red w/stainless steel housing
80336R Red w/polished stainless steel housing
• Mounts flush to vehicle
• Allows for easy bulb replacement
• Not intended for P2 use
0.20 screw hole diameter
4.94 bolt hole circle
4.50 mounting hole
5.50
3.95
2.09
80302R Red lamp
80302Y Yellow lamp
80304
Clear lamp, B/U
• Features rubber housing for shock absorbency
• Snap-in lens for quick bulb replacement
• Mounts flush to vehicle with recessed lens
• Not intended for use as (P2) clearance
0.188 screw hole diameter
5.000 bolt hole circle
4.500 mounting hole
5.50
2.00
4.45
1.31
80339R Red
80336R
See Pages 6 - 10
80302Y
See Pages 6 - 10
See Pages 6 - 10
