FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
18
6.49
2.32
1.02
1.75
LED
Stop/Turn/Tail
10 Diode Pattern
Material:
• Acrylic lens
& housing
Light Source:
• LED
• 10 Diodes
• 12 V, 0.02/0.172 A
FMVSS:
• FMVSS P2; FMVSS I6;
FMVSS S2 (3); FMVSS T
• Engineered to feature ten bright and economical light emitting diodes (LEDs)
• When properly mounted, exceeds FMVSS-P2 DOT requirements for marker/clearance performance
• Designed with impact-resistant acrylic material
• Sealed lens and housing locks moisture out
• Snap fit grommet requires no screws for installation
• LEDs do not have a filament, therefore are not susceptible to shock and vibration damage major cause of failure for
lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• Popular on owner/operator and show trucks
• Lamps come with Truck-Lite 2-Year Limited Warranty
6058 Lamp, red
• Mount horizontally or vertically
• Right angle plug assembly
60002R Red, grommet kit
60002Y Yellow, grommet kit
60007R Red, grommet kit, 24v
60007Y Yellow, grommet kit, 24v
Super 60
®
Stop/Turn/Tail
& Front/Park/Turn
Sealed
Material:
• Polycarbonate lens
& housing
• PVC grommet
• 16 gauge wire
Light Source:
• 12v designed at 12.8 V,
2.1/.48 A, 32/2 cp
• 24 V designed at 28 V,
.93/.34 A 32/6 cp
Kit Components:
60002R/Y grommet kits:
1 - 60202R/Y 12v lamp
1 - 60700 grommet
1 - 94993 plug
60007R/Y grommet kits:
1 - 60207R/Y 24v lamp
1 - 60700 grommet
1 - 94993 plug
FMVSS:
• Red - I6,P2,S2,T
• Yellow - I6,P2,P
6.50
2.50
2.25
60002R
See Page 16
60202R Red lamp
60202Y Yellow lamp
60207R Red lamp, 24v
60207Y Yellow lamp, 24v
