FRONT & REAR LIGHTING
UNI
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
21
Die Cast
Stop/Turn/Tail
Bulb Replaceable
Material:
• Metal die cast housing
• Acrylic lens
Light Source:
• #1156 12 V bulb, one wire
• #1157 12 V bulb, two wire
Replacement Parts:
• 9016 red lens
• 9016W clear lens
• 9021 red lens kit
• 9021W clear lens kit
• 9102 plug, one wire
• 9101 plug, two wire
FMVSS:
• Red - I,P2,S,T
• Narrow depth behind flange allows
lamp to fit where other lamps cannot
• Mounts through 4-1/2” diameter
cut-out, 2” depth below flange
3612
5.28
4.875" DIA
1.33
4.3
1.98
See Pages 6 - 10
3612
Red, S/T/T, gray housing
3616
Red, S/T/T, chrome housing
3613W Clear, B/U, chrome housing
(utility or dome)
• Mounts in 7.83” x 4.43” hole
• Requires separate reflector to
meet legal requirements
Universal Mount
Stop/Turn/Tail
Bulb Replaceable
Material:
• Polycarbonate lens
& housing
Light Source:
• Bulb #1157
Replacement Parts:
• 9041 red lens
• 9041A yellow lens
FMVSS:
• Red - I,P,S,T
• License - L
• Two wire
3.46
2.00
.82
4.25
Two stud mount
41202R
41203R
540D
41 Series Stop/Turn/Tail
Sealed
Material:
• Polycarbonate lens & housing
• 16 gauge wire
Light Source:
• Dual filament bulb
• Designed at 12.8 V, 2.1/.48 A, 32/2 cp
Kit Components:
41005R LH kit:
1 - 41202R & 41203R lamp
1 - 94948 LH plug
41006R RH kit:
1 - 41202R & 41203R lamp
1 - 94949 RH plug
41007R universal kit:
1 - 41202R & 41203R lamp
2 - 94926 universal plug
41008R universal kit:
1 - 41202R & 41203R lamp
FMVSS:
• I,S,T
4.46
8.80
4.40
4.44
1.80
5.40
41005R Red, LH kit
41006R Red, RH kit
41007R Red, universal kit
41008R Red, universal kit w/o plugs
41202R Red, LH
41203R Red, RH
540D
Red w/license, two stud, retail pack
541
Red w/o license, two stud
