18 / 348
FRONT & REAR LIGHTING
UNI
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
16
6050A
6051
6051A
6050
LED
Stop/Turn/Tail &
Front/Park Turn
24 Diode Pattern
Material:
• Polycarbonate lens
& housing
Light Source:
• LED
• Designed at 13.5 V,
.030/.380 A
Recommended Accessories:
• Mounting: Pages 256-257
• Plugs: Pages 207-209
FMVSS:
• Red - I6,P2,S2,(3)T
• Yellow - I6,P2,P
• Uses standard right Angle plug
• Unique LED array displays full pattern light output design
• Epoxy encapsulated electronics prevents damage from moisture & corrosion
6.49
2.32
1.02
1.75
6050
Red lamp
6050A Yellow lamp
6051
Red lamp w/clear lens
6051A Yellow lamp w/clear lens
LED
Stop/Turn/Tail
Integral Flange
24 Diode Pattern
Material:
• Polycarbonate lens
& housing
Light Source:
• LED
• 24 Diodes
• 12 V, 0.02/0.26 A
FMVSS:
• FMVSS P2; FMVSS I6;
FMVSS S2 (3); FMVSS T
• Housing and flange are molded together to form one piece
• Uses standard right angle PL-3 connection
• Designed with impact-resistant polycarbonate material
• LEDs do not have a filament, therefore are not susceptible to shock and
vibration damage major cause of failure for lamps with an incandescent bulb
• Epoxy encapsulated electronics prevents damage from moisture and corrosion
• When properly mounted, exceeds FMVSS DOT requirements for S/T/T and F/P/T
• Lamps come with Truck-Lite 2-Year Limited Warranty
6053 Integral flange, lamp, red
6.74”
3.31”
7.87”
7.24”
6.74”
3.31”
7.87”
7.24”
