Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
229
HARNESS SYSTEMS
HAR
A
Part No.
52724 0288
52727 0324
52730 0360
52733
52736 0432
52739 0468
52742 0504
Dim. “A”
288”
324”
360”
396”
432”
468”
504”
Part No.
52745 0540
52748 0576
52751
52754 0648
52757 0684
52760 0720
52763 0756
Dim. “A”
540”
576”
612”
648”
684”
720”
756”
Part No.
52703 0036
52706 0072
52709 0108
52712 0144
52715 0180
52718 0216
52721 0252
Dim. “A”
36”
72”
108”
144”
180”
216”
252”
A
1-8 gauge, 2-10 gauge, 4-12 gauge
7 Conductor Main Cable
6 Conductor Main Cable
Part No.
50124 0288
50127 0324
50130 0360
50133
50136 0432
50139 0468
50142 0504
Dim. “A”
288”
324”
360”
396”
432”
468”
504”
Part No.
50145 0540
50148 0576
50151
50154 0648
50157 0684
50160 0720
50163 0756
Dim. “A”
540”
576”
612”
648”
684”
720”
756”
Part No.
50103 0036
50106 0072
50109 0108
50112 0144
50115 0180
50118 0216
50121 0252
Dim. “A”
36”
72”
108”
144”
180”
216”
252”
Dimensions “A” indicate standard stocked length harness. A range of custom length harnesses
are available in 12” increments. Contact Customer Service for lead time and availability.
A
1-10 gauge, 5-12 gauge
Single Plug Turn/Tail Harness
Dim “A” Custom Dim
50266 R.H. turn/tail harness, white/green/brown 456”
192” - 444”
50267 L.H. turn/tail harness, white/yellow/brown 456”
192” - 444”
A
3 conductor flat cable
A
3 conductor flat cable
3 conductor flat cable
Single Plug Stop/Turn/Tail Harness
Dim “A” Custom Dim
50325 Stop/turn/tail harness, white/red/black
180”
12” - 168”
50338 Stop/turn/tail harness, white/red/black
456”
192” - 444”
50342 R.H. turn/marker harness, white/green/brown 180”
12” - 168”
50343 L.H. turn/marker harness, white/yellow/brown 180”
12” - 168”
50344 R.H. turn/marker harness, white/green/brown 456”
192” - 444”
50345 L.H. turn/marker harness, white/yellow/brown 456”
192” - 444”
LED Single Plug Stop/Turn/Tail Harness
Dim “A” Custom Dim
51344 R.H. turn/tail harness, white/green/brown 420”
12” - 408”
51345 L.H. turn/tail harness, white/yellow/brown 420”
12” - 408”
51325 Stop/tail harness, white/red/black
180”
348”
