JUNCTION BOXES & RECEPTACLES
HAR
10.08 9.50
2.25
5.47
3.09
• For 2 conductor cable.
50840 3/8” I.D. fitting
• For 6 & 7 conductor cable.
50842 3/4” I.D. fitting
• For 3 conductor flat cable.
50846 Fitting
• A 3-part fitting consisting of a pre-tapped cap, a threaded base and a black PVC grommet
that is available with 6 different hole sizes to accommodate various conductor cables.
• For 4 & 5 conductor cable.
50841 -1/2” I.D. fitting
• For single conductor wire.
50843 5-hole fitting
• For 4 cond
50847 Fitting
• Steel clips
• Supplied with all multi-plug S/T/T harness
• 50% more harness ports; alleviates
need for multiple boxes while allowing
additional harness systems and increased
lighting
• Larger box makes it easier to work on
internal connections
• Clear lid offers easy viewing of
connections, saving time when identifying
lighting system problems
• Dual “Dogbone” ground strap feature allows 4 terminals to be common, replacing
need for multiple junction boxes and saving costs
• Silicone gasket on lid helps eliminate damage from moisture and corrosives
• High impact, chemical resistant, approved insulated plastic provides long life,
eliminates time & money for repair & replacement
• Mounted by 4 eyelet reinforced holes in base of box for increased durability
• Contains 12 pre-tapped holes to accept compression fittings or filler plugs for
greater configuration versatility
• Uses 50 Series compression fittings or 50830 filler plugs (6 included in kit)
Compression Fittings
50840
2 conductors, 3/8” fitting
50841
4 & 5 conductors, 1/2” fitting
50842
6 & 7 conductors, 3/4” fitting
50843
Single conductor wire, 5 hole fitting
50846
3 conductor flat cable fitting
50847
4 conductor flat cable fitting
DOG BONE
CLEAR LID
GASKET
EYELETS
Super 50
®
Junction Box
Material:
• Grey ABS plastic box
• Clear polycarbonate lid
• 12 ports
• 16 terminal studs with
4-common grounds
50600 Kit:
1 - Grey ABS junction box
1 - Clear polycarbonate lid w/
screws
1 - Terminal block w/hardware
1 - Ground strap
1 - Dual ground strap
6 - 50830 filler plugs
50600
Super 50® 12 port junction box kit
50601
Super 50® junction box
50606
Super 50® junction box cap w/screws
50607
Replacement lid & gasket
50608
Super 50® ground strap
50609
Super 50® dual ground strap
50830
Filler plug
50832 Replacement lid, gasket & 6 screws
97913 Straight mold, 1-1/2” steel
97011 Right angle, 1-1/4” steel
