232 / 348
HARNESS SYSTEMS
HAR
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
230
LED Stop/Turn/Tail Harness
Dim “A” Custom Dim.
50240 R.H. stop/turn/tail harness
72”
12” - 96”
50241 L.H. stop/turn/tail harness
72”
12” - 96”
A
1.5 Diameter
18.00
A
13.00
1.25Diameter
5 conductor round cable
5 conductor round cable
A
4.50
13.00
5.00
7.00
A
13.00
1.25Diameter
5 conductor round cable
5 conductor round cable
Dimensions “A” indicate standard stocked length harness. A range
of custom length harnesses are available in 12” increments. Contact
Customer Service for lead time and availability.
5 conductor round cable
Stop/Turn/Tail Harness
Dim “A” Custom Dim.
50200 R.H. stop/turn/tail harness
72”
12” - 60”
50201 L.H. stop/turn/tail harness
72”
12” - 60”
50202 R.H. stop/turn/tail harness
156”
84” - 144”
50203 L.H. stop/turn/tail harness
156”
84” - 144”
ABS Power Jumper Harness
Dim “A” Custom Dim.
52100 ABS power harness
720”
120” - 600”
Connect from nosebox or 50-series junction box
3 conductor 12 gauge flat cable for use with 50847
compression fitting to connect with 50-series junction box
3 Plug Stop/Turn/Tail and Back-Up Harness
Dim “A” Custom Dim.
50204 R.H. 3 plug stop/turn/tail harness 72”
12” - 60”
50205 L.H. 3 plug stop/turn/tail harness 72”
12” - 60”
50250 L.H. 2 plug S/T/T & back-up harness 144”
84” - 132”
50251 R.H. 2 plug S/T/T & back-up harness 144”
84” - 132”
LED 3 Plug Stop/Turn/Tail Harness
Dim “A” Custom Dim.
51270 R.H. 3 plug S/T/T harness
96”
12” - 192”
51271 L.H. 3 plug S/T/T harness
96”
12” - 192”
Stop/Turn/Tail and Side Marker Harness
Dim “A” Custom Dim.
50208 R.H. S/T/T & side marker harness 96”
12” - 84”
50209 L.H. S/T/T & side marker harness 96”
12” - 84”
50210
R.H. S/T/T & side marker harness 192”
108” - 180”
50211 L.H. S/T/T & side marker harness 192”
108” - 180”
