BRAKE DRUM NUMERICAL SECTION
Drum
Number
Weight Type Mount
Backface
Thickness
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Special
Information
No. Size
66878F
104
K O 0.50
16.50 10.25 7.38
9.00
10.83
8 1.00
66880B
OBSOLETE - Use 66892B
66883B 107
K O 0.50
16.50 10.35 7.54
8.53
11.25 10 0.81
Notched
66883F
107
K O 0.50
16.50 10.35 7.54
8.53
11.25 10 0.81
Notched
66884B 117
K O 0.50
16.50 10.62 7.62
8.78
11.25 10 1.00 *See footer.
Use 66661B for
severe service.
66884F
119
K O 0.50
16.50 10.62 7.62
8.78
11.25 10 1.00 *See footer.
Use 66661B for
severe service.
66886B 124 M O 0.50
16.50 10.19 7.38
12.75
11.25 10 0.81 9.44 Hub Bore
66888F
110
K O 0.50
16.50 10.62 7.81
9.00
11.25 10 1.31
66889F
OBSOLETE - Use 66893F
66890B 111
K O 0.50
16.50 10.62 7.62
8.74
11.25 10 0.81
66892B 106
K O 0.50
16.50 10.25 7.38
8.53
11.25 10 0.81
66892F
106
K O 0.50
16.50 10.25 7.38
8.53
11.25 10 0.81
66893B 113
K O 0.50
16.50 10.62 7.62
8.53
11.25 10 0.81
66893F
114
K O 0.50
16.50 10.62 7.62
8.53
11.25 10 0.81 *See footer.
66895B 110
K O 0.50
16.50 10.62 7.81
9.00
11.25 10 0.81 *See footer.
66896F
111
K O 0.50
16.50 10.38 7.38
8.66
11.25 10 0.81
66899B 123 M O 0.50
16.50 10.19 7.38
12.75
11.25 10 1.31 9.44 Hub Bore
67101B
OBSOLETE - Use 66893B
67156B
OBSOLETE - Use 61574F
67205F
135
H I
0.50
16.50 11.94 10.34
9.44
11.25 10 0.94
67407B
OBSOLETE - Use 62200F
67415B
OBSOLETE - Use 68730F
67434B
OBSOLETE - Use 66814F
67486B
OBSOLETE - Use 66814F
67515F
OBSOLETE - Use 67518F
67518B
98
G I
0.50
16.50
8.38 7.38
9.44
11.00
5 0.78
6 0.66
67518F
100 G I
0.50
16.50
8.38 7.38
9.44
11.00
5 0.78 *See footer.
6 0.66
67537F
102 G I
0.50
16.50
8.38 7.38
9.44
11.25 10 0.81
67598F
OBSOLETE - Use 67518F
67615B
OBSOLETE - Use 66815B
67945B
OBSOLETE - Use 65550B
68012F
112
H I
0.56
16.50
9.00 7.62
9.50
11.25 5/6 0.78
Notched
68013F
112
H I
0.56
16.50
9.00 7.62
9.50
11.25 10 0.81
Notched
68036F**
104
H I
0.50
16.50
8.78 6.72
9.75
11.25
5 0.66
Notched
68114B
OBSOLETE - Use 65541B
68530F
OBSOLETE - Use 68730F
68565F
OBSOLETE - Use 68765F
68647F
OBSOLETE - Use 63647F
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
