BRAKE DRUM PROGRESSIVE SECTION
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Drum
Number Weight Type Mount
Backface
Thickness
Special
Information
No. Size
15.00 BRAKE SURFACE DIAMETER
15.00 9.31
5.40
8.78
11.25 10 1.00 65153B 82
K O 0.50
15.00 9.31
5.40
8.78
11.25 10 1.31 65154B 82
K O 0.50
15.00 9.44
7.50
9.75
11.25 5 0.66 61548F 93
H I
0.50
15.00 9.46
6.26
8.78
11.25 10 1.00 61951B 72
K O 0.50
Approved for 19.5
disc wheels.
15.00 9.49
6.18
8.78
11.25 10 1.00 65145B 110
F
O 0.62
15.00 9.49
6.18
9.00
11.25 10 1.31 65147B 108
F
O 0.62
15.00 9.75
7.52
8.78
11.25 10 1.00 61510B 91
K O 0.50
15.00 9.81
6.50
9.00
11.25 10 1.31 65157B 111
H O 0.62
15.00 9.84
6.64
8.78
11.25 10 1.00 61950B 77
K O 0.50
Approved for 19.5
disc wheels.
15.00 9.84
6.64
8.78
11.25 10 1.09 61959B 77
K O 0.50
15.00 9.84
6.64
9.00
10.83 8 1.00 61958B 78
K O 0.50
Approved for 19.5
disc wheels.
15.00 10.09 7.25
8.53
11.25 10 0.81 61574F 98
K O 0.50
15.00 10.38 7.56
8.53
11.25 10 0.81 61591F 102
K O 0.50
For Girling Brakes.
15.00 10.41 7.57
8.78
11.25 10 1.00 61567B 97
K O 0.50
15.00 10.41 7.57
8.78
11.25 10 1.00 61567F 97
K O 0.50
15.00 10.59 7.75
8.53
11.25 10 0.81 61571F 106
K O 0.50
15.00 10.59 7.75
9.00
10.83 8 1.00 61576B 105
K O 0.50
15.00 10.59 7.75
9.00
10.83 8 1.00 61576F 105
K O 0.50
15.00 10.59 7.75
8.78
11.25 10 1.00 61577B 104
K O 0.50
15.00 10.59 7.75
8.78
11.25 10 1.00 61577F 104
K O 0.50
15.00 10.93 7.50
6.44
8.75
6 0.81 61586F 101
K O 0.44
15.00 11.59 9.21
8.78
11.25 10 1.00 61988B 110
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.59 9.21
8.78
11.25 10 1.00 61988F 112
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.59 9.21
9.00
10.83 8 1.00 61989B 105
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.59 9.21
9.00
10.83 8 1.00 61989F 105
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.75 9.22
8.78
11.25 10 1.00 61991B 118
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.75 9.22
8.78
11.25 10 1.00 61991F 118
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.75 9.22
8.78
11.25 10 1.09 61992F 118
K O 0.50
Approved for 19.5
disc wheels.
15.00 11.75 9.22
9.00
10.83 8 1.00 61999F 118
K O 0.50
Approved for 19.5
disc wheels.
15.00 12.38 10.15 12.75
11.25 10 1.31 64038F 177
Q O 0.50
9.44 Hub Bore.
Vert. Ribbed.
Notched.
15.14 BRAKE SURFACE DIAMETER
15.14 8.65
6.50
12.75
11.25 10 1.31 64046B 119
M O 0.50
9.44 Hub Bore.
Notched.
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
