BRAKE DRUM PROGRESSIVE SECTION
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Drum
Number Weight Type Mount
Backface
Thickness
Special
Information
No. Size
14.50 BRAKE SURFACE DIAMETER
14.50 8.69
6.44
12.75
11.25 10 1.31 64117B 110
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
14.50 8.69
6.44
12.75
11.25 10 1.31 64117J
110
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
14.50 8.69
6.44
12.75
11.25 10 1.31 65119J
112
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
14.50 11.50 8.31
13.00
11.25 10 1.31 64009B 145
Q O 0.50
9.44 Hub Bore.
Vert. Ribbed.
14.50 11.79 8.50
12.75
11.25 10 1.31 64073B 136
H O 0.50
9.44 Hub Bore.
14.50 11.79 8.50
12.75
11.25 10 1.31 64073F 136
H O 0.50
9.44 Hub Bore.
14.50 12.81 10.50 12.75
11.25 10 1.31 64015B 172
M O 0.50
9.44 Hub Bore.
*See footer.
14.50 12.81 10.50 12.75
11.25 10 1.31 64115B 179
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
14.50 12.81 10.50 12.75
11.25 10 1.31 64115C 179
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
14.50 12.81 10.50 12.75
11.25 10 1.31 64115J
179
O O 0.50
9.44 Hub Bore.
Circum. Ribbed.
*See footer.
15.00 BRAKE SURFACE DIAMETER
15.00 3.94
3.45
10.00
11.25 5 0.53 64016F 37
A
I
0.41
15.00 4.14
3.45
10.00
11.00 5 0.53 64018F 38
A
I
0.41
15.00 4.42
3.88
9.00
10.50 5 0.66 64413F 52
A
I
0.38
15.00 4.69
3.50
6.44
8.00
5 0.66 64453F 44
N I
0.44
15.00 5.28
4.25
9.50
11.25 6 0.78 64478F 59
N I
0.50
15.00 5.28
4.32
6.44
8.00
5 0.66 64477F 59
G I
0.50
15.00 5.38
4.50
9.25
11.25 5 0.78 64417F 66
G I
0.53
15.00 5.55
4.44
9.19
11.25 5/6 0.66 64414F 64
G I
0.50
15.00 5.55
4.44
9.19
11.25 5/6 0.78 64444F 60
G I
0.50
15.00 5.84
4.50
9.25
11.25 5/6 0.78 65514B 68
G I
0.50
15.00 5.88
4.94
10.00
12.75 5/6 0.78 63294F 62
G I
0.50
15.00 6.41
4.44
6.25
8.75
6 0.81 64426F 58
H I
0.38
15.00 7.00
5.36
9.37
11.25 10 0.81 61526F**
69
K
I
0.44
15.00 7.06
6.38
9.44
11.00 5/6 0.66 61566F 70
A
I
0.50
15.00 7.25
5.53
6.25
8.75
6 0.81 64408F**
77
H I
0.50
15.00 7.38
6.50
11.25
12.75 5/6 0.66 61601F 82
A
I
0.50
15.00 7.44
6.38
11.25
12.75 6 0.78 65256B 91
G I
0.50
15.00 7.56
5.50
9.50
11.25 10 0.81 61554F 67
G I
0.50
15.00 7.84
4.44
8.66
11.25 10 1.31 64481F 72
H O 0.50
15.00 7.84
4.44
8.78
11.25 10 1.31 64489F 72
H O 0.50
15.00 7.84
4.44
9.44
11.25 10 0.81 64483F 75
H O 0.50
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
