BRAKE DRUM NUMERICAL SECTION
Drum
Number
Weight Type Mount
Backface
Thickness
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Special
Information
No. Size
68958F
93
F
I
0.50
16.50
8.19 7.19
14.25
12.75
5 0.78 11.25 Hub Bore
6 0.66
68967F
OBSOLETE - Use 61727F
68970B**
82
A I
0.50
16.50
6.88 6.10
11.25
12.75
5 0.66
6 0.78
68981B 100 G I
0.50
16.50
8.44 7.37
11.25
12.75 5/6 0.78 *See footer.
68984F
OBSOLETE - Use 68981B
68985F
85
H O 0.50
16.50
8.56 5.44
8.78
11.25 10 1.00
68986B 102 G I
0.53
16.50
8.53 7.44
11.42
13.19
6 0.66
68988F
84
H O 0.50
16.50
8.56 5.44
8.66
11.25 10 1.31
68989F
84
H O 0.50
16.50
8.56 5.44
8.78
11.25 10 1.31
69378B
OBSOLETE - Use 65167B
69870B
OBSOLETE - Use 61528B
69996B
OBSOLETE - Use 66864F
76864B 102
V O 0.50
16.50 10.54 7.54
8.78
11.25 10 1.00 *See footer.
77528B
64
V O 0.50
15.00
8.89 4.70
8.78
11.25 10 1.31 Vortex Unlimited
77710B
79
V O 0.50
16.50
9.39 5.70
8.78
11.25 10 1.31 Vortex Unlimited
77800BW 117
V O 0.56
16.50 11.15 8.66
8.78
11.25 10 1.00 Vortex Unlimited
77854BW 119
V O 0.56
16.50 11.46 9.05
8.78
11.25 10 1.00 Vortex Unlimited
77864BW 109
V O 0.48
16.50 10.54 7.54
8.78
11.25 10 1.00 Vortex Unlimited
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
