BRAKE DRUM PROGRESSIVE SECTION
Brake
Surface
Diameter
Overall
Depth
Brake
Surface
Flat
Pilot
Diameter
Bolt
Circle
Diameter
Bolt Holes
Drum
Number Weight Type Mount
Backface
Thickness
Special
Information
No. Size
15.00 BRAKE SURFACE DIAMETER
15.00 7.94
6.69
14.25
12.75 5 0.66 64028F 73
P
I
0.50
11.25 Hub Bore.
15.00 8.00
5.56
6.44
8.75 10 0.78 64404F 78
N I
0.44
15.00 8.00
5.56
6.44
8.75
6 0.81 64405F 78
N I
0.44
15.00 8.00
5.56
6.51
8.75
6 0.81 64403F 77
K
I
0.44
15.00 8.00
5.56
6.51
8.75 10 0.78 64432F 75
K
I
0.44
15.00 8.02
4.32
9.00
11.25 10 1.31 61511F 73
K O 0.50
15.00 8.02
5.50
6.25
8.75
6 0.81 65735F 75
K O 0.44
15.00 8.06
3.75
7.12
8.75
6 0.81 64449F 65
K O 0.44
15.00 8.12
7.32
9.50
11.25 5/6 0.78 61595F**
88
G I
0.50
15.00 8.16
6.97
11.00
12.50 5/6 0.66 61612F**
84
G I
0.50
15.00 8.25
3.75
9.50
11.25 10 0.81 64445F 65
K O 0.38
15.00 8.38
7.19
11.00
12.50 5/6 0.66 61599F**
87
G I
0.50
15.00 8.38
7.19
11.25
12.75 5/6 0.78 61600B**
86
G I
0.50
15.00 8.50
6.50
9.75
11.25 5 0.66 64105F 83
N I
0.50
15.00 8.50
7.50
10.50
12.75 5/6 0.78 63035F 96
H I
0.56
15.00 8.53
4.50
8.75
11.25 10 0.81 64454F 73
H O 0.44
15.00 8.54
6.41
6.25
8.75
6 0.84 61536F 80
K
I
0.50
15.00 8.62
7.44
11.00
12.50 5/6 0.66 61606F**
88
G I
0.50
15.00 8.75
6.55
12.75
11.25 10 1.31 64036F 129
Q O 0.50
9.44 Hub Bore.
Vert. Ribbed.
Notched.
15.00 8.76
4.50
8.78
11.25 10 1.31 65547B 82
H O 0.62
*See footer.
15.00 8.76
4.50
9.00
11.25 10 1.31 65541B 80
H O 0.62
15.00 8.76
4.50
9.00
11.25 10 0.81 65542B 81
H O 0.62
15.00 8.79
6.56
9.00
10.83 8 1.00 66830B 81
K O 0.50
15.00 8.86
4.78
8.75
11.25 10 1.31 61529B 70
H O 0.50
15.00 8.86
4.78
8.75
11.25 10 1.31 61529F 70
H O 0.50
15.00 8.86
4.78
8.78
11.25 10 1.00 61527B 70
K O 0.50
*See footer.
15.00 8.86
4.78
8.78
11.25 10 1.31 61528B 70
H O 0.50
*See footer.
15.00 8.89
4.70
8.78
11.25 10 1.31 77528B 64
V O 0.50
Vortex Unlimited
15.00 8.98
4.75
8.75
11.25 10 0.81 65546B 77
H O 0.50
15.00 9.04
4.50
8.78
11.25 10 1.00 65545B 68
H O 0.50
*See footer.
15.00 9.04
4.50
8.78
11.25 10 1.00 65555B 81
M O 0.50
15.00 9.04
4.50
8.78
11.25 10 1.00 65565B 80
H O 0.50
15.00 9.04
4.50
8.78
11.25 10 1.31 65548B 78
H O 0.50
*See footer.
15.00 9.04
4.50
9.00
11.25 10 1.31 65549B 81
H O 0.50
15.00 9.04
4.75
9.00
10.83 8 1.00 65543B 80
H O 0.50
15.00 9.10
8.32
11.06
13.19 10 1.09 64044F 94
G O 0.50
15.00 9.15
7.40
11.22
13.19 10 0.94 64049B 96
G O 0.55
15.00 9.10
5.50
8.53
11.25 10 1.31 65550B 85
H O 0.50
15.00 9.10
5.50
8.78
11.25 10 1.31 65554B 83
H O 0.50
15.00 9.10
5.50
9.00
11.25 10 1.28 65551B 81
H O 0.50
Mount I=Inboard, O=Outboard
See Page 4 for Obsolete with No Replacement Brake Drums.
*Available for purchase through the pallet program. See Page 6 for pallet part numbers.
**Will become obsolete when current inventory is depleted. Call for availability - if purchased, parts are non-returnable.
